Dorman 2630317 Fuel Pump Module Assembly

Vehicle Compatibility Chart

Part Attributes

• Average Current Draw:
  6.5
• Connector Color:
  White
• Connector Gender:
  Female
• Connector Shape:
  Rectangle
• Fuel Sending Unit Included:
  Yes
• Fuel Tank Pressure Sensor Included:
  Yes
• Fuel Type:
  Gas
• Gasket Or Seal Included:
  Yes
• Gasket Or Seal Material:
  Rubber
• Grade Type:
  Regular
• Height:
  325
• Housing Length:
  183
• Housing Material:
  Plastic
• Housing Width:
  90.06
• In Tank or External:
  In Tank
• Inlet Outside Diameter:
  8
• Inlet Quantity:
  1
• Inlet Type:
  Flanged
• Internal Or External Strainer:
  Internal
• Length:
  325
• Lock Ring Included:
  No
• Maximum Flow Rating:
  15.2 GPH
• Maximum Pressure:
  66 PSI
• Minimum Free Flow Rate:
  15.2 GPH
• Minimum Pressure:
  56 PSI
• Mounting Hardware Included:
  No
• Negative Ground:
  Yes
• Outlet Diameter:
  9.5 mm
• Outlet Outside Diameter:
  8
• Outlet Quantity:
  1
• Outlet Type:
  Flanged
• Package Contents:
  1 Fuel Pump Module Assembly; 1 Harness; 4 Butt Connectors; 4 Heat Shrink Tubes
• Pump Type:
  Electric
• Regulator Included:
  No
• Resistance Ohms Empty:
  20
• Resistance Ohms Full:
  90
• Socket Gender:
  Electric In-tank
• Strainer Included:
  Yes
• Terminal Gender:
  Male
• Terminal Quantity:
  4
• Terminal Type:
  Blade
• Top Mount Diameter:
  113
• Universal Or Specific Fit:
  Specific
• Voltage:
  15
• Width:
  4.768
• Wire Harness Included:
  No
