Airtex E8368M Fuel Pump Module Assembly

Reliable Fuel Pump Module Assembly for Volkswagen and Audi

The Airtex E8368M fuel pump module assembly is designed specifically for select Volkswagen Passat and Audi A6, including A6 Quattro models. This electric in-tank fuel pump ensures consistent fuel delivery with a 12-volt power supply and a flow rate of 32 gallons per hour, meeting the demands of regular grade fuel systems.

• Compatible with Volkswagen Passat and Audi A6, A6 Quattro
• Electric in-tank fuel pump module assembly
• 12-volt operation with 32 GPH flow rate
• Includes external strainer and gasket for secure installation
• Pin-type terminals with male connector, 2-terminal configuration
• Outlet hose connection with 1.0 inch outside diameter
• Negative ground system compatible

Technical Details and Features

The Airtex E8368M fuel pump module assembly is engineered for specific fitment, ensuring proper integration with the fuel system of Volkswagen Passat and Audi A6 models. It features an electric pump type with a minimum flow rating of 32 gallons per hour, suitable for regular grade fuel. The module includes an external strainer inlet type to protect the pump from debris, and a gasket is included to maintain a secure seal during installation. The outlet is designed for hose connection with a 1.0 inch outside diameter, and the terminal type is pin with two terminals and a male connector gender. This module is designed for negative ground electrical systems and operates at 12 volts. Mounting hardware, fuel sending unit, regulator, lock ring, wiring harness, and fuel tank pressure sensor are not included with this assembly.

Applications and Problem Resolution

• Replaces faulty or failing fuel pump modules in Volkswagen Passat and Audi A6 vehicles
• Addresses fuel delivery issues such as engine hesitation or stalling
• Resolves low fuel pressure problems affecting engine performance
• Prevents fuel pump noise caused by clogged or damaged strainers
• Restores proper fuel flow rate for consistent engine operation

Installation Notes and Tips

Installation of the Airtex E8368M fuel pump module assembly requires removal of the fuel tank to access the in-tank pump. Ensure the gasket included is properly seated to prevent fuel leaks. Verify the negative ground system compatibility and confirm the pin-type terminals match the vehicle’s wiring harness. Since mounting hardware and wiring harness are not included, reuse existing components or source compatible parts separately. Handle the external strainer carefully to avoid damage during installation.

Quality Assurance and Warranty

Airtex fuel pump modules are manufactured to meet OEM specifications for fit, form, and function. The E8368M part number undergoes rigorous quality control to ensure reliable operation in Volkswagen Passat and Audi A6 vehicles. This product includes a gasket for installation integrity. Warranty coverage details should be confirmed with the distributor or retailer, as it may vary by region.
