Anchor 6083 Drive Shaft Center Support Bearing - Front

Overview of Anchor Drive Shaft Center Support Bearing 6083

The Anchor Drive Shaft Center Support Bearing 6083 is designed for reliable driveline performance in select Lexus and Toyota models. Engineered with a round frame and wings, this bearing supports the drive shaft to reduce vibration and maintain alignment.

• Bearing ID / Bore: 1.1811 inch (30 mm)
• Centerline offset: 0.10 inch (3 mm)
• Mount width: 7.00 inch (178 mm)
• Style: Round frame with wings for secure mounting
• Compatible with Lexus and Toyota Highlander, RX300, RX330, RX350, RX400h, RX450h

Technical Details and Specifications

This drive shaft center support bearing features a 1.1811 inch (30 mm) bore size, ensuring a precise fit for the drive shaft assembly. The 0.10 inch (3 mm) centerline offset helps maintain proper alignment under load, reducing wear on the driveline components. With a mount width of 7.00 inches (178 mm), the bearing provides stable support and vibration dampening. The round frame style with integrated wings allows for secure installation and durability in demanding driving conditions.

Compatible Vehicles and Applications

This Anchor part number 6083 is compatible with a range of Lexus and Toyota vehicles, including the Highlander and RX series models such as RX300, RX330, RX350, RX400h, and RX450h. It is specifically designed to meet the driveline requirements of these vehicles, ensuring proper fit and function.

Common Issues Addressed by This Bearing

• Excessive drive shaft vibration or noise
• Misalignment of the drive shaft causing premature wear
• Worn or damaged center support bearing leading to driveline instability
• Reduced driveline performance due to bearing failure
• Loose or unstable mounting of the drive shaft assembly

Installation Notes and Tips

When installing the Anchor Drive Shaft Center Support Bearing 6083, ensure the bearing bore matches the drive shaft diameter of 1.1811 inches (30 mm). Proper alignment of the centerline offset (0.10 inch / 3 mm) is critical to avoid driveline imbalance. The mount width of 7.00 inches (178 mm) should be securely fastened using the integrated wings to prevent movement during operation. It is recommended to inspect the drive shaft and related components for wear before installation.

Quality Assurance and Warranty

Anchor manufactures this center support bearing to meet OEM specifications for Lexus and Toyota vehicles. The part number 6083 undergoes quality control testing to ensure durability and performance. While specific warranty details are not provided, Anchor products typically conform to industry standards for driveline components.
