Anchor 9507 Engine Torque Strut Mount - Rear - view 1
Anchor 9507 Engine Torque Strut Mount - Rear - view 2
Anchor 9507 Engine Torque Strut Mount - Rear - view 3
Anchor 9507 Engine Torque Strut Mount - Rear - view 4
Anchor 9507 Engine Torque Strut Mount - Rear - view 5
Anchor 9507 Engine Torque Strut Mount - Rear - view 6
Anchor 9507 Engine Torque Strut Mount - Rear - view 7
Anchor 9507 Engine Torque Strut Mount - Rear - view 8
Part #: 9507

Anchor 9507 Engine Torque Strut Mount - Rear

Rear
⚙️ 13 vehicles fit this part
🔍
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
$60.58Free Shipping
🚚Free ShippingNo Cost to Continental U.S.
🔄Free Returns*Wrong fit? No cost
🛡️60-Day ReturnsMoney back guarantee
*Free return shipping only qualifies if our fitment verification tool is used.
🔥
✅ In Stock · Ready To Ship Most orders ship same-day if ordered before 1pm CST.
✅OE Direct Replacement — Bolt-on fit, no modifications needed
🚗Fitment: Mazda, CX-9 and CX-7
🔄Easy Returns — Return within 60 days for a full refund
🚚Fast Shipping — Most orders ship same business day before 1pm CST
Not what you need? Click here for all Engine Torque Strut Mount options

Overview of Anchor Engine Torque Strut Mount 9507

The Anchor Engine Torque Strut Mount 9507 is designed specifically for Mazda CX-7 and CX-9 models. This component plays a critical role in stabilizing engine movement and reducing vibrations during operation.

  • Large end inner diameter: 0.52 inch (13.20 mm)
  • Small end inner diameter: 0.48 inch (12.20 mm)
  • Compatible with Mazda CX-7 and CX-9 vehicles
  • Part number: 9507 for precise identification

Technical Details and Specifications

The Anchor Engine Torque Strut Mount 9507 features a large end inner diameter of 0.52 inch (13.20 mm) and a small end inner diameter of 0.48 inch (12.20 mm). These dimensions ensure a secure fit and proper alignment within the engine assembly. The torque strut mount is engineered to absorb and dampen engine torque forces, minimizing stress on the engine and transmission mounts. This part is essential for maintaining engine stability and smooth operation in Mazda CX-7 and CX-9 models.

Application and Common Issues Addressed

This engine torque strut mount is compatible with Mazda CX-7 and CX-9 vehicles and is used to address several common engine mounting issues:

  • Excessive engine vibration during acceleration or idling
  • Engine movement causing noise or clunking sounds
  • Premature wear of other engine mounts due to torque stress
  • Reduced driveline stability affecting vehicle handling

Installation Notes and Tips

When installing the Anchor Engine Torque Strut Mount 9507, ensure the correct orientation of the large and small ends based on the specified inner diameters. Proper torque specifications should be followed to avoid over-tightening or under-tightening, which can affect mount performance. It is recommended to inspect surrounding mounts and components for wear during installation to maintain overall engine stability.

Quality Assurance and Warranty Information

Anchor manufactures the Engine Torque Strut Mount 9507 to meet OEM standards for fit and function. This part undergoes quality control inspections to ensure durability and reliability. While specific warranty details may vary, Anchor typically offers coverage against manufacturing defects to provide confidence in the product's performance for Mazda CX-7 and CX-9 applications.

BrandAnchor
Part Number9507
LARGE END ID0.52 INCH / 13.20 MM
SMALL END ID0.48 INCH / 12.20 MM

This part fits 13 vehicles. Search below:

YearMakeModelDrive TypeTransmissionLitersCylindersPositionNotes
2015MazdaCX-93.7LV6RearLOWER; 1ST DESIGN; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2014MazdaCX-93.7LV6RearLOWER; 1ST DESIGN; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2013MazdaCX-93.7LV6RearLOWER; 1ST DESIGN; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2012MazdaCX-93.7LV6RearLOWER; 1ST DESIGN; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2011MazdaCX-93.7LV6RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2010MazdaCX-93.7LV6RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2009MazdaCX-93.7LV6RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2008MazdaCX-7AWDAutomatic2.3LL4RearLOWER; ; TO 9/1/2008; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM; ; AT;
2008MazdaCX-7FWDAutomatic2.3LL4RearLOWER; ; TO 9/1/2008; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM; ; AT;
2008MazdaCX-93.7LV6RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;
2007MazdaCX-7AWDAutomatic2.3LL4RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM; ; AT;
2007MazdaCX-7FWDAutomatic2.3LL4RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM; ; AT;
2007MazdaCX-93.5LV6RearLOWER; ; LARGE END ID:0.52 INCH / 13.20 MM; SMALL END ID:0.48 INCH / 12.20 MM;

* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.

This part directly replaces or is cross-referenced with the following part numbers:

Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
