Autobest F2982A Fuel Pump Module Assembly

Overview of Autobest Fuel Pump Module Assembly F2982A

The Autobest Fuel Pump Module Assembly F2982A is designed for reliable fuel delivery in Chevrolet and GMC full-size vans. Engineered to meet the specific requirements of Express and Savana models, this in-tank fuel pump module ensures consistent performance and compatibility.

• Average current draw of 8.5 amps for efficient operation
• Fuel flow rating of 41 gallons per hour (GPH)
• Includes fuel sending unit and fuel tank pressure sensor
• Equipped with a male rectangular connector, single connector quantity
• Inlet and outlet quick connect fittings (5/16" inlet, 3/8" outlet)
• Includes NBR gasket/seal for secure installation
• Maximum pump pressure of 145 PSI and minimum of 87 PSI
• Constructed with durable POM housing material
• Compatible with Chevrolet Express 1500, 2500, 3500 and GMC Savana 1500, 2500, 3500

Technical Details and Specifications

The Autobest F2982A fuel pump module assembly operates with an average current draw of 8.5 amps, delivering a steady fuel flow rate of 41 GPH. This module is designed as an in-tank unit, featuring a POM housing for durability and resistance to fuel corrosion. The assembly includes a fuel sending unit and a fuel tank pressure sensor, providing accurate fuel level and pressure monitoring. The connector is a single male rectangular type, facilitating straightforward electrical connections. Both inlet and outlet ports use quick connect fittings, sized 5/16" and 3/8" respectively, to simplify fuel line attachment. The included NBR gasket ensures a proper seal to prevent leaks. Operating pressures range from 87 to 145 PSI, suitable for the fuel system requirements of the specified Chevrolet and GMC vans.

Compatible Vehicles and Applications

This fuel pump module assembly is compatible with the following vehicles:

• Chevrolet Express 1500, 2500, 3500
• GMC Savana 1500, 2500, 3500

It is intended for use in fuel delivery systems requiring an in-tank pump module with integrated sending unit and pressure sensor, ensuring proper fuel supply and accurate fuel level readings.

Common Issues Addressed by This Fuel Pump Module

• Intermittent or no fuel delivery causing engine stalling or failure to start
• Inaccurate fuel gauge readings due to faulty sending unit
• Fuel system pressure irregularities affecting engine performance
• Leaks or poor sealing in the fuel pump assembly area
• Electrical connector failures leading to pump malfunction

Installation Notes and Tips

The Autobest F2982A is designed for direct replacement in compatible Chevrolet Express and GMC Savana models. Installation requires removal of the fuel tank to access the in-tank pump module. The included NBR gasket should be replaced to ensure a proper seal. The quick connect inlet and outlet fittings simplify fuel line connections, and the single male rectangular connector allows for straightforward electrical hookup. No special mounting hardware is included, so retain original components if possible. Follow all safety precautions when working with fuel system components.

Quality Assurance and Warranty

Manufactured in China, the Autobest F2982A fuel pump module assembly meets regular grade standards for fuel delivery components. It is available to order and backed by Autobest's quality control processes. While specific warranty details should be confirmed at the point of purchase, Autobest products typically include coverage against manufacturing defects to ensure reliability and customer confidence.
