Autobest F3004A Fuel Pump Module Assembly

Overview of Autobest Fuel Pump Module Assembly F3004A

The Autobest Fuel Pump Module Assembly F3004A is designed for reliable fuel delivery in Dodge Ram 1500, Ram 2500, and Ram 3500 trucks. This in-tank fuel pump module ensures consistent fuel flow and pressure to support engine performance.

• Average current draw of 9.5 amps for efficient operation
• Fuel flow rating of 150 gallons per hour (GPH)
• Includes fuel sending unit and FKM gasket for secure sealing
• In-tank design with internal strainer and 0.433 inch inlet size
• Single female rectangular connector for easy electrical connection
• Maximum pump pressure of 54 PSI and minimum pressure of 48 PSI
• Outlet quick connect fitting sized at 3/8 inch
• Durable POM housing material for long-lasting use

Technical Details and Specifications

The Autobest F3004A fuel pump module assembly is engineered with a POM housing material that provides durability and resistance to fuel corrosion. It features an internal strainer inlet type to prevent debris from entering the fuel system. The module includes a fuel sending unit for accurate fuel level readings and an FKM gasket to ensure a tight seal within the fuel tank. The pump operates within a pressure range of 48 to 54 PSI, delivering a steady flow rate of 150 GPH, suitable for the fuel demands of Dodge Ram 1500, Ram 2500, and Ram 3500 models. The electrical connector is a single female rectangular type, simplifying installation and connection.

Compatible Vehicles and Applications

This fuel pump module assembly is compatible with the following Dodge models:

• Dodge Ram 1500
• Dodge Ram 2500
• Dodge Ram 3500

It is designed specifically for in-tank installation, replacing the original fuel pump module to restore proper fuel delivery and fuel level sensing functions.

Common Issues Addressed by This Fuel Pump Module

• Intermittent or no fuel delivery causing engine stalling or failure to start
• Inaccurate fuel gauge readings due to faulty sending unit
• Low fuel pressure affecting engine performance and fuel efficiency
• Fuel pump noise or failure from worn internal components
• Fuel leaks caused by degraded or missing gaskets

Installation Notes and Tips

The Autobest F3004A fuel pump module assembly is designed for direct replacement with no special installation warnings. Ensure the fuel tank is properly drained and depressurized before removal. Verify the connector type and orientation to match the vehicle’s wiring harness. Replace the FKM gasket included with the module to maintain a secure seal and prevent leaks. Use appropriate tools to avoid damage to the fuel tank or module during installation.

Quality Assurance and Warranty

Manufactured in China, the Autobest F3004A meets regular grade standards for fuel pump modules. The product is available to order and includes a fuel sending unit and gasket for comprehensive replacement. While specific warranty details are not provided, Autobest products typically adhere to industry quality controls to ensure reliable performance in Dodge Ram 1500, Ram 2500, and Ram 3500 trucks.
