Autobest F4261 Fuel Pump and Strainer Set

Overview of Autobest Electric Fuel Pump F4261

The Autobest Electric Fuel Pump F4261 is designed for reliable fuel delivery in select Volvo models. Engineered as an in-tank turbine pump, it provides consistent fuel flow and pressure to support engine performance in vehicles like the Volvo 850, 940, and V70.

• Average current draw of 6.8 amps for efficient operation
• Fuel flow rating of 120 gallons per hour (GPH)
• Maximum pump pressure of 123.3 PSI and minimum pressure of 79.8 PSI
• Inlet size of 0.465 inches with strainer inlet type
• Outlet hose connection with 0.346 inch outlet size
• Negative ground electrical system compatibility
• Includes pump and installation kit (gasket or seal not included)
• Two male chip-type terminals for electrical connection
• Compact dimensions: 5.2 inches length, 1.69 inches width and height

About the Autobest Electric Fuel Pump Product Line

The Autobest Electric Fuel Pump line focuses on delivering dependable in-tank fuel pumps designed to meet OEM specifications. The F4261 model exemplifies this line by combining turbine pump technology with precise flow and pressure ratings, ensuring consistent fuel delivery for Volvo vehicles. This product line supports maintenance and repair needs by providing components engineered for durability and compatibility.

Detailed Product Description

The F4261 fuel pump from Autobest is an in-tank turbine pump engineered to maintain optimal fuel pressure and flow in Volvo models including the 850, 940, 960, C70, S70, S90, V70, and V90. With an average flow rating of 120 GPH and a pressure range between 79.8 and 123.3 PSI, it supports efficient fuel delivery under various driving conditions. The pump operates with a 6.8 amp current draw and features a negative ground electrical system, making it compatible with the specified Volvo vehicles. The inlet uses a strainer type to help prevent debris from entering the fuel system, while the outlet is designed for hose connection with a 0.346 inch diameter. The package includes the pump and installation kit, though gaskets or seals are not provided.

Common Applications and Issues Addressed

• Replacement for failing or weak fuel pumps in Volvo 850, 940, and V70 models
• Resolves low fuel pressure causing engine hesitation or stalling
• Addresses inconsistent fuel flow impacting vehicle performance
• Fixes electrical issues related to pump current draw and grounding
• Supports restoration of fuel system reliability in aging vehicles

Installation Notes and Tips

The Autobest F4261 fuel pump is designed for in-tank installation with no special installation warnings. Ensure the vehicle’s electrical system is negative ground compatible before installation. Since the package does not include gaskets or seals, verify the condition of existing seals or source replacements as needed. Properly connect the two male chip-type terminals to maintain secure electrical contact. Follow vehicle-specific service manuals for safe removal and installation procedures.

Quality Assurance and Warranty

The Autobest Electric Fuel Pump F4261 is available to order and meets quality standards for aftermarket fuel delivery components. While specific warranty details are not provided, Autobest products typically adhere to industry standards for durability and performance. Confirm warranty terms with the supplier or manufacturer prior to purchase.
