Autobest F4494A Fuel Pump Module Assembly

Reliable Fuel Pump Module Assembly for Honda and Isuzu Vehicles

The Autobest F4494A fuel pump module assembly is engineered to provide consistent fuel delivery for select Honda and Isuzu models. Designed as an in-tank unit, this assembly integrates essential components to maintain optimal fuel system performance.

• Average current draw of 9 amps for efficient power consumption
• Fuel flow rating of 41 gallons per hour (GPH) to support engine demands
• Includes fuel sending unit and fuel tank pressure sensor for accurate fuel level and pressure monitoring
• Equipped with a male rectangular connector, single connector quantity for straightforward electrical connection
• Constructed with durable POM housing and NBR gasket for reliable sealing
• Quick connect inlet (5/16") and outlet (3/8") for simplified installation
• Compatible with Honda Axiom and Isuzu Passport and Rodeo models

Product Features and Specifications

The Autobest F4494A fuel pump module assembly operates within a pressure range of 87 to 145 PSI, ensuring stable fuel delivery under varying engine conditions. Its in-tank design helps reduce noise and heat exposure, contributing to longer component life. The included fuel sending unit and tank pressure sensor provide integrated monitoring capabilities, eliminating the need for separate parts. The assembly’s connector is a single male rectangular type, facilitating a secure and reliable electrical connection. The housing is made from POM material, known for its strength and chemical resistance, while the NBR gasket ensures a tight seal to prevent leaks.

Compatible Vehicles and Applications

This fuel pump module assembly is compatible with the following vehicles:

• Honda Axiom
• Isuzu Passport
• Isuzu Rodeo

It is designed to replace the original equipment fuel pump module in these models, restoring proper fuel delivery and system functionality.

Common Issues Addressed by This Fuel Pump Module

• Intermittent or complete fuel delivery failure
• Inaccurate fuel level readings due to faulty sending unit
• Fuel pressure irregularities causing engine performance issues
• Fuel leaks from worn or damaged seals
• Electrical connection problems affecting pump operation

Installation Notes and Tips

The Autobest F4494A is an in-tank fuel pump module assembly designed for direct replacement. It features quick connect inlet and outlet fittings (5/16" inlet and 3/8" outlet) to simplify hose connections. The package includes the pump and module but does not include mounting hardware, so retain original hardware or source separately if needed. No special installation warnings are noted, but standard safety precautions for fuel system work should be followed. Ensure all electrical connections are secure and the gasket is properly seated to prevent leaks.

Quality Assurance and Warranty

Manufactured in China, the Autobest F4494A meets regular grade standards for fuel pump modules. It includes a NBR gasket for reliable sealing and is available to order with consistent quality control. Warranty details should be confirmed at the point of purchase, as coverage may vary.
