Autobest F7266A Fuel Pump Hanger Assembly

Fuel Pump Hanger Assembly Overview

Autobest F7266A is a fuel pump hanger assembly for in-tank fuel delivery systems. It is built as a performance-grade replacement with a turbine pump, integrated fuel sending unit, and external strainer for service on classic Chevrolet and GMC truck and Suburban applications.

Fits 1987-1991 Chevrolet and GMC applications listed below, including R/V series trucks and Suburban models with the specified primary fuel tank configuration. This part number, F7266A, is also cross-referenced to Delphi HP10255 and US Motor Works USEP05M for the same application.

Key Features

• In-tank fuel pump hanger assembly for direct fuel delivery service
• Turbine pump design with 12V operation and 25 GPH average flow rating
• Includes a fuel sending unit and external strainer
• Female connector with rectangular shape and two-pin terminal layout
• NBR seal material and negative-ground electrical setup
• Performance-grade construction for fuel system replacement work

Detailed Description

Autobest F7266A is intended for Chevrolet and GMC fuel system repairs where the hanger assembly, pump, and sender are serviced together. The unit uses a turbine-style pump, one outlet, and a female electrical connector, with resistance values of 2 ohms empty and 94 ohms full for the sending unit. The compact assembly measures 11.4 inches high, 4.3 inches long, and 3.62 inches wide, and the part number F7266A should be matched to the exact tank and configuration notes shown in the fitment data.

Compatible With Chevrolet and GMC truck and Suburban applications from 1987-1991, including Chevrolet R10, R20, R30, R2500, R2500 Suburban, R3500, V10, V20, V20 Suburban, V30, V2500 Suburban, V3500, and GMC R1500, R2500, R2500 Suburban, R3500, V1500, V2500, V2500 Suburban, V3500. Use the listed notes to confirm driver-side mounted primary fuel tank coverage where required. F7266A is a direct-fit fuel pump hanger assembly for these applications.

What It Is Used For

• Replacing a worn or failed in-tank fuel pump hanger assembly
• Restoring fuel delivery on Chevrolet and GMC truck fuel systems
• Addressing inaccurate fuel level readings from a failing sender
• Correcting fuel starvation caused by pump or strainer wear
• Servicing assemblies with tank-specific hanger and seal requirements

Installation Notes and Tips

Verify the vehicle year, model, tank configuration, and fitment notes before ordering. This assembly is for in-tank use and does not include mounting hardware or a wire harness. Confirm connector style, sender resistance range, and tank application against the original unit before installation. The part number F7266A should be matched carefully to the listed Chevrolet and GMC applications.

Quality Assurance

Autobest F7266A is backed by a limited lifetime warranty. The assembly is built as a performance-grade fuel system replacement and is supplied with the fuel sending unit and strainer included.
