Autobest F8690A Fuel Pump Module Assembly
| Brand | Autobest F8690A |
|---|---|
| Average Current Draw(A) | 13 |
| Average Flow Rating(GPH) | 55 |
| Connector Gender | Female |
| Connector Quantity | 2 |
| Connector Shape | Rectangle |
| Country of Orign | China |
| Fuel Filter Included | Yes |
| Fuel Sending Unit Included | Yes |
| Fuel Tank Pressure Sensor Included | No |
| Gasket Or Seal Material | Nitrile rubber |
| Grade Type | Premium |
| Housing Material | Plastic |
| In Tank or External | In tank |
| Internal Or External Strainer | Internal |
| Life Cycle Status Code | Available to order |
| Mounting Hardware Included | No |
| Negative Ground | No |
| Outlet Quantity | 1 |
| Package Contents | Pump & module |
| Product Height (in) | 7.5 |
| Product Length (in) | 13 |
| Product Width (in) | 9.5 |
| Resistance Ohms Empty | 990 |
| Resistance Ohms Full | 51 |
| Short Description | Fuel pump module assembly |
| Strainer Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 4 |
| Terminal Type | Pin |
| UPC | 00072845186904 |
| Product line | Fuel Pump Module Assembly |
| Fits | BMW · 21 vehicles |
Complete module assembly. Includes the pump, filter, sending unit, and internal strainer in one service part.
Premium-grade build. Plastic housing and nitrile rubber seal material support tank-mounted fuel system service.
Electrical specs matched. 12-volt operation with a 13-amp average current draw and 55 GPH flow rating.
Cross-references Delphi FG1689 and USEP8960M for the same application. See all 2.
Fuel Pump Module Assembly Overview
Autobest F8690A is a premium in-tank fuel pump module assembly for BMW X5 and BMW X6 applications. It combines the pump, fuel filter, fuel sending unit, and internal strainer in one service part for direct fuel system replacement.
Key Features
- In-tank fuel pump module assembly for fuel delivery service
- Includes fuel filter, fuel sending unit, and strainer
- Female 2-connector design with 4-pin male terminals
- 12-volt operation with 13-amp average current draw
- Nitrile rubber seal material and plastic housing
- Premium grade construction
Detailed Description
Autobest F8690A is built for BMW X5 and BMW X6 fuel system service where a complete module assembly is needed. The unit is designed as an in-tank replacement with one outlet, internal strainer, and integrated sending unit, helping restore fuel delivery and fuel level signal function in a single service part. The module uses a rectangular female connector layout and is specified with a 55 GPH average flow rating, 12-volt electrical operation, and a 13-amp average current draw. This part cross-references Delphi FG1689 and USEP8960M for the same application.
The Fuel Pump Module Assembly line from Autobest focuses on complete fuel delivery components rather than individual pump pieces. For BMW X5 and BMW X6 service, F8690A provides the core module hardware needed for a full tank-mounted replacement, with the filter and sending unit already integrated into the assembly. The part number F8690A is useful when matching an OE-style fuel pump module assembly by application and connector configuration.
What It Is Used For
- Restoring fuel pressure when the pump is worn or failing
- Correcting inaccurate fuel level readings from a faulty sender
- Replacing a clogged internal filter or strainer
- Addressing hard-start or no-start conditions tied to fuel delivery
- Servicing a leaking or degraded tank-mounted module seal
Installation Notes and Tips
Fits 2008 BMW X6, N/A. Fits 2009-2019 BMW X6, N/A. Fits 2010-2018 BMW X5, N/A. Verify connector shape, terminal count, and tank configuration before installation. This in-tank module does not include mounting hardware or a wire harness. Confirm the original part number F8690A and compare the existing module layout to the replacement before service.
Quality Assurance
Autobest lists this fuel pump module assembly with a limited lifetime warranty. The premium-grade design, integrated sending unit, and complete module construction support consistent fuel system service for BMW X5 and BMW X6 applications.
| Year | Make | Model | Submodel | Liters | Cylinders | Notes |
|---|---|---|---|---|---|---|
| 2019 | BMW | X6 | M | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2018 | BMW | X5 | M | 4.4L | V8 | Fuel Pump Module Assembly |
| 2018 | BMW | X6 | M | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2017 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2017 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2016 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2016 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2015 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2015 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2014 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2014 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2013 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2013 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2012 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2012 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2011 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2011 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2010 | BMW | X5 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| 2010 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2009 | BMW | X6 | — | 4.4L | V8 | United States; Fuel Pump Module Assembly |
| 2008 | BMW | X6 | — | 4.4L | V8 | Fuel Pump Module Assembly |
| No rows match your filter. | ||||||
