BBB Industries 101-0152 Rack and Pinion Assembly
| Brand | BBB Industries 101-0152 |
|---|---|
| "Hydraulic, Electric or Manual Steering" | Hydraulic |
| Bushings Included | Yes |
| Distance Between Front Mounting Holes (In) | 11.2 |
| Distance Between Front Mounting Holes (mm) | 285 |
| Distance Between Mounting Holes (In) | 11.714 |
| Distance Between Mounting Holes (mm) | 297.543 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rod Length (In) | 10.8 |
| Inner Tie Rod Length (mm) | 275 |
| Inner Tie Rod Size | M14x1.50 |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.72 |
| Input Shaft Diameter (mm) | 18.5 |
| Input Shaft Length (In) | 1.9 |
| Input Shaft Length (mm) | 48.5 |
| Installation Kit Included | Yes |
| New or Remanufactured | Manufactured New |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Attachment Type | Manifold |
| Pressure Port Size | 11mm |
| Pressure Port Thread Size | 11mm |
| Rack Length (In) | 44.8 |
| Rack Length (mm) | 1138 |
| Return Port Attachment Type | Manifold |
| Return Port Size | 9.5mm |
| Return Port Thread Size | 9.5mm |
| Turns Lock To Lock | 3.5 |
| Product line | Reman Rack and Pinion |
| Fits | Ford · 4 vehicles |
Hydraulic steering. Built for smooth, responsive steering control.
Manufactured new. A reman rack and pinion assembly with fresh components.
Installation kit included. Comes with bushings and inner tie rods for easier setup.
Cross-references 1L5Z-3504-HA, 1L5Z-3504-HARM and 19320290 for the same application. See all 3.
Hydraulic Rack and Pinion for Explorer Sport Trac
BBB Industries 101-0152 is a manufactured-new hydraulic rack and pinion assembly for select Ford Explorer Sport Trac models with power steering. It is built for direct replacement service and includes the key mounting and steering connection details needed for a proper repair.
For Ford Explorer Sport Trac steering repair, this BBB Industries Reman Rack and Pinion line part number 101-0152 is specified for 2002 and 2003-2005 applications with hydraulic steering. It is a fitment-focused replacement for vehicles that need restored steering response and correct rack geometry.
Key Features
- Hydraulic rack and pinion assembly
- Manufactured new construction
- Inner tie rods included
- Bushings included
- Installation kit included
- Pressure port attachment type: manifold
- Return port attachment type: manifold
- Turns lock to lock: 3.5
- Rack length: 44.8 in. (1138 mm)
- Input shaft diameter: 0.72 in. (18.5 mm)
Product Details
BBB Industries 101-0152 is part of the Reman Rack and Pinion product line and is engineered for hydraulic steering systems. The assembly uses a 2-hole mounting design, M14x1.50 inner tie rod size, and manifold-style pressure and return ports sized at 11 mm and 9.5 mm. It is listed with a 11.2 in. front mounting hole spacing and 11.714 in. mounting hole spacing, which helps confirm application-specific fitment during replacement work.
Fits 2002 Ford Explorer Sport Trac, power steering, from 9/1/01. Fits 2003-2005 Ford Explorer Sport Trac, power steering. This part cross-references 1L5Z-3504-HA and 19320290 for the same application.
Common Steering Problems This Part Addresses
- Excessive steering play or loose steering feel
- Fluid leakage from the rack and pinion assembly
- Hard steering or inconsistent hydraulic assist
- Worn internal rack components affecting road control
- Noisy steering operation caused by internal wear
Installation Notes and Tips
Confirm hydraulic steering, mounting-hole spacing, input shaft dimensions, and port sizes before installation. Transfer or connect the steering system components according to the vehicle’s service procedure, then bleed the hydraulic system after installation to remove trapped air and restore normal steering assist.
Quality Assurance
BBB Industries supplies this rack and pinion as a manufactured-new replacement part for hydraulic steering applications. Verify vehicle build date and steering configuration against the listed fitment before installation on Ford Explorer Sport Trac models.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2005 | Ford | Explorer Sport Trac | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2004 | Ford | Explorer Sport Trac | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2003 | Ford | Explorer Sport Trac | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2002 | Ford | Explorer Sport Trac | N/A | Power Steering; From 9/1/01; Reman Rack and Pinion |
| No rows match your filter. | ||||
