BBB Industries 101-0155 Rack and Pinion Assembly
| Brand | BBB Industries 101-0155 |
|---|---|
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 11.375 |
| Distance Between Mounting Holes (mm) | 288.925 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (In) | 1.5 |
| Input Shaft Length (mm) | 38.1 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M16X1.50 |
| Rack Length (In) | 44.75 |
| Rack Length (mm) | 1136.65 |
| Return Port Thread Size | M16X1.50 |
| Turns Lock To Lock | 3.5 |
| Product line | Reman Rack and Pinion |
| Fits | Mazda · 9 vehicles |
Remanufactured unit. A reman rack and pinion assembly for a cost-conscious replacement.
Hydraulic steering. Delivers traditional power-assisted steering response and feel.
Inner tie rods included. Saves time by adding a key steering component to the assembly.
Cross-references 19320293 for the same application. See all 1.
Reman Rack and Pinion for Mazda B-Series
BBB Industries Reman Rack and Pinion 101-0155 is a hydraulic rack and pinion assembly built for steering service on select Mazda B2500, B3000, and B4000 Cab Plus models. It includes inner tie rods and is remanufactured to match the original hydraulic steering layout for direct replacement service.
Key Features
- Brand: BBB Industries Reman Rack and Pinion
- Part number: 101-0155
- Hydraulic rack and pinion assembly
- Remanufactured unit
- Inner tie rods included
- Pressure port thread size: M16x1.50
- Return port thread size: M16x1.50
- Rack length: 44.75 in. (1136.65 mm)
- Distance between mounting holes: 11.375 in. (288.925 mm)
- Turns lock to lock: 3.5
- Input shaft diameter: 0.75 in. (19.05 mm)
- Input shaft length: 1.5 in. (38.1 mm)
Product Details
BBB Industries 101-0155 is part of the Reman Rack and Pinion line, a product line focused on remanufactured steering gear assemblies for vehicles that require hydraulic steering response and OE-style fitment. This rack and pinion assembly is specified for 1998-2000 Mazda B2500, Mazda B3000, and Mazda B4000 models with power steering and Cab Plus configuration. The design uses two mounting holes and the listed port and shaft dimensions to match the original steering system layout.
This part cross-references Monroe Shocks & Struts (e.g., 19320293) for the same application. The part number 101-0155 is also a useful reference when verifying steering gear replacement for Mazda B-Series trucks.
Vehicle Fitment
- Fits 1998-2000 Mazda B2500, N/A, Power Steering; Cab Plus; Reman Rack and Pinion
- Fits 1998-2000 Mazda B3000, N/A, Power Steering; Cab Plus; Reman Rack and Pinion
- Fits 1998-2000 Mazda B4000, N/A, Power Steering; Cab Plus; Reman Rack and Pinion
Common Steering Issues This Part May Address
- Excessive steering play or loose on-center feel
- Fluid leakage from the steering gear housing or ports
- Hard steering effort caused by worn hydraulic rack components
- Uneven steering response from internal wear in the rack assembly
- Noisy steering operation related to worn rack and pinion internals
Installation Notes and Tips
Verify the hydraulic port thread sizes, input shaft dimensions, mounting-hole spacing, and rack length before installation. Confirm the vehicle is a power steering Cab Plus application for 1998-2000 Mazda B2500, B3000, or B4000. Inspect related steering components, flush the hydraulic system as needed, and align the front end after replacement.
Quality Assurance
BBB Industries remanufactures steering components to meet application-specific replacement requirements for hydraulic rack and pinion service. Part number 101-0155 is built for direct-fit replacement on the listed Mazda B-Series applications.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2000 | Mazda | B2500 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 2000 | Mazda | B3000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 2000 | Mazda | B4000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1999 | Mazda | B2500 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1999 | Mazda | B3000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1999 | Mazda | B4000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1998 | Mazda | B2500 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1998 | Mazda | B3000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
| 1998 | Mazda | B4000 | N/A | Power Steering; Cab Plus; Reman Rack and Pinion |
