BBB Industries 101-0249 Rack and Pinion Assembly
| Brand | BBB Industries 101-0249 |
|---|---|
| "Hydraulic, Electric or Manual Steering" | Hydraulic |
| Bushings Included | Yes |
| Distance Between Back Mounting Holes (In) | 25.1 |
| Distance Between Back Mounting Holes (mm) | 640 |
| Distance Between Front Mounting Holes (In) | 16.1 |
| Distance Between Front Mounting Holes (mm) | 410 |
| Distance Between Mounting Holes (In) | 16 |
| Distance Between Mounting Holes (mm) | 406.4 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rod Length (In) | 9.3 |
| Inner Tie Rod Length (mm) | 237 |
| Inner Tie Rod Size | M16x1.50 |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.72 |
| Input Shaft Diameter (mm) | 18.5 |
| Input Shaft Length (In) | 1.2 |
| Input Shaft Length (mm) | 32.5 |
| Installation Kit Included | Yes |
| New or Remanufactured | Manufactured New |
| Number of Mounting Holes | 4 |
| Outer Tie Rods Included | No |
| Pressure Port Attachment Type | O-Ring |
| Pressure Port Size | M14X1.50 |
| Pressure Port Thread Size | M16X1.50 |
| Rack Length (In) | 47.1 |
| Rack Length (mm) | 1198 |
| Return Port Attachment Type | O-Ring |
| Return Port Size | M16X1.50 |
| Return Port Thread Size | M14X1.50 |
| Turns Lock To Lock | 3 |
| Product line | Reman Rack and Pinion |
| Fits | Lincoln and Ford · 17 vehicles |
Hydraulic steering. Built for smooth, responsive steering performance.
Installation kit included. Helps simplify the replacement process.
Reman rack and pinion. A steering gear assembly from BBB Industries.
Cross-references 19320337 and BT4Z-3504-A for the same application. See all 2.
Hydraulic Rack and Pinion for Edge and MKX
BBB Industries Reman Rack and Pinion 101-0249 is a hydraulic rack and pinion assembly for Ford Edge and Lincoln MKX applications with power steering. It is built for direct replacement service on supported vehicles and includes the key hydraulic connections, inner tie rods, bushings, and installation kit listed in the product data.
Key Features
- Hydraulic rack and pinion assembly for steering service
- Fits Ford Edge and Lincoln MKX hydraulic power steering applications
- Rack length: 47.1 in. (1198 mm)
- Turns lock to lock: 3
- Inner tie rods included with M16x1.50 size
- Bushings included
- Installation kit included
- Pressure port: O-ring, M14x1.50 thread size
- Return port: O-ring, M16x1.50 thread size
- Input shaft diameter: 0.72 in. (18.5 mm)
Product Details
BBB Industries 101-0249 is part of the Reman Rack and Pinion line, a steering component range focused on replacement rack assemblies for hydraulic steering systems. This unit is manufactured new and built to match the listed mounting and hydraulic dimensions, including 4 mounting holes, 16 in. mounting hole spacing, and the specified front and back mounting hole distances. It cross-references Monroe Shocks & Struts 19320337 and BT4Z-3504-A for the same application. Use this part number 101-0249 when sourcing a hydraulic rack and pinion for 2007-2015 Ford Edge and Lincoln MKX models with the listed steering configuration and wheel exclusions.
What It Helps Address
- Excessive steering play or loose steering feel
- Hydraulic steering fluid leaks at the rack assembly
- Binding, rough steering, or inconsistent steering response
- Worn inner tie rod connection points
- Noise or vibration from a worn steering gear assembly
Installation Notes
Verify hydraulic steering type, mounting dimensions, and port thread sizes before installation. This assembly is listed for 2007-2008 Ford Edge and Lincoln MKX with power steering, 2009-2010 Ford Edge and Lincoln MKX excluding 22-inch wheels, and 2011-2014 Ford Edge plus 2011-2015 Lincoln MKX with hydraulic steering excluding 22-inch wheels. Confirm the vehicle’s steering configuration and port attachment style against the original unit before replacement. Professional alignment is recommended after steering gear replacement.
Quality Assurance
BBB Industries supplies this reman rack and pinion under its steering component program, with the product built to the listed specifications for hydraulic steering service. Part number 101-0249 is identified for direct application matching on the supported Ford Edge and Lincoln MKX fitments.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2015 | Lincoln | MKX | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2014 | Ford | Edge | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2014 | Lincoln | MKX | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2013 | Ford | Edge | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2013 | Lincoln | MKX | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2012 | Ford | Edge | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2012 | Lincoln | MKX | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2011 | Ford | Edge | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2011 | Lincoln | MKX | N/A | Power Steering; (Hydraulic Steering) (Exc. 22" Wheels); Reman Rack and Pinion |
| 2010 | Ford | Edge | N/A | Power Steering; Exc. 22" Wheels; Reman Rack and Pinion |
| 2010 | Lincoln | MKX | N/A | Power Steering; Exc. 22" Wheels; Reman Rack and Pinion |
| 2009 | Ford | Edge | N/A | Power Steering; Exc. 22" Wheels; Reman Rack and Pinion |
| 2009 | Lincoln | MKX | N/A | Power Steering; Exc. 22" Wheels; Reman Rack and Pinion |
| 2008 | Ford | Edge | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2008 | Lincoln | MKX | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2007 | Ford | Edge | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2007 | Lincoln | MKX | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
