BBB Industries 102-0154 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion for Chrysler PT Cruiser

The BBB Industries Reman Rack and Pinion Assembly (part number 102-0154) is designed specifically for Chrysler PT Cruiser models. This remanufactured hydraulic rack and pinion unit offers precise steering control and reliable performance for your vehicle's steering system.

• Remanufactured hydraulic rack and pinion assembly
• Compatible with Chrysler PT Cruiser
• Includes inner tie rods; outer tie rods not included
• Input shaft diameter: 0.75 inches (19.05 mm)
• Input shaft length: 1.75 inches (44.45 mm)
• Rack length: 47 inches (1193.8 mm)
• Distance between mounting holes: 3.63 inches (92.202 mm)
• Pressure port thread size: M18x1.50
• Return port thread size: M16x1.50
• Turns lock to lock: 2.813

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries focuses on providing remanufactured steering components that meet OEM specifications. This product line ensures that each rack and pinion assembly undergoes a thorough remanufacturing process to restore functionality and durability. The 102-0154 part maintains hydraulic steering compatibility and includes inner tie rods to simplify installation for Chrysler PT Cruiser owners.

Product Description and Specifications

This remanufactured rack and pinion assembly features a hydraulic design tailored for the Chrysler PT Cruiser. The input shaft measures 0.75 inches in diameter and 1.75 inches in length, providing a precise fit for the vehicle's steering column. The rack length of 47 inches ensures proper engagement with the steering components. The assembly includes two mounting holes spaced 3.63 inches apart, facilitating secure installation. Inner tie rods are included, but outer tie rods and bushings are not part of this assembly. Thread sizes for the pressure and return ports are M18x1.50 and M16x1.50 respectively, matching factory specifications.

Common Applications and Issues Addressed

• Restores steering responsiveness and control on Chrysler PT Cruiser
• Replaces worn or leaking hydraulic rack and pinion assemblies
• Eliminates excessive play or steering wheel vibration
• Corrects uneven or difficult steering effort
• Addresses fluid leaks from pressure or return ports

Installation Notes and Tips

When installing the BBB Industries Reman Rack and Pinion 102-0154 on a Chrysler PT Cruiser, ensure the mounting holes align precisely with the vehicle frame using the 3.63-inch spacing. Verify that the input shaft diameter and length match the steering column specifications. Since outer tie rods and bushings are not included, inspect and replace these components separately if necessary. Properly torque all mounting bolts and check hydraulic connections at the M18x1.50 pressure port and M16x1.50 return port to prevent leaks.

Quality Assurance and Warranty

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards for fit, form, and function. The 102-0154 part is built to restore steering performance reliably. Warranty coverage details should be confirmed at the point of purchase, as BBB Industries typically offers limited warranties on remanufactured steering components to ensure customer confidence.
