BBB Industries 102-0163 Rack and Pinion Assembly
| Brand | BBB Industries 102-0163 |
|---|---|
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 3.69 |
| Distance Between Mounting Holes (mm) | 93.726 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (In) | 1.75 |
| Input Shaft Length (mm) | 44.45 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M18X1.50 |
| Rack Length (In) | 47 |
| Rack Length (mm) | 1193.8 |
| Return Port Thread Size | M16X1.50 |
| Turns Lock To Lock | 2.75 |
| Product line | Reman Rack and Pinion |
| Fits | Chrysler · 5 vehicles |
Remanufactured unit. A cost-conscious replacement for restoring steering performance.
Hydraulic design. Delivers familiar steering feel with proven assist technology.
Inner tie rods included. Simplifies the job with key components already in place.
Cross-references 5272722AG and 19320388 for the same application. See all 2.
Reman Rack and Pinion for PT Cruiser
BBB Industries Reman Rack and Pinion 102-0163 is a hydraulic steering gear assembly built for Chrysler PT Cruiser applications with standard steering. It is remanufactured to restore steering response, rack travel, and hydraulic assist performance for the listed model years.
The BBB Industries Reman Rack and Pinion line focuses on remanufactured steering components for direct replacement service. Part number 102-0163 is specified for Chrysler PT Cruiser vehicles with power steering and the listed OE and stamping references.
- Hydraulic rack and pinion assembly
- Inner tie rods included
- Remanufactured steering gear
- 47 in. rack length
- 2.75 turns lock to lock
- Pressure port thread size: M18x1.50
- Return port thread size: M16x1.50
- Input shaft diameter: 0.75 in.
- Distance between mounting holes: 3.69 in.
Detailed Product Overview
This rack and pinion assembly is designed for Chrysler PT Cruiser steering systems that use hydraulic assist and standard steering (SBA). The unit measures 47 inches in rack length, uses two mounting holes, and includes inner tie rods for a more complete steering gear replacement. Part number 102-0163 also cross-references OE numbers 5272722AG and 19320388 for the same application.
Fits 2007 Chrysler PT Cruiser, N/A; Power Steering, w/ Standard Steering (SBA), w/ OE No. 5272722AG. Fits 2005-2006 Chrysler PT Cruiser, N/A; Power Steering with Standard Steering (SBA). Fits 2004 Chrysler PT Cruiser, N/A; compatible with vehicles equipped with power steering. Fits 2003 Chrysler PT Cruiser, N/A; Power Steering, w/ 4656746AK Stamped on Rack.
What This Part Helps Address
- Excessive steering play or looseness
- Uneven or delayed steering response
- Hydraulic steering gear leakage at the rack
- Worn internal rack components affecting control
- Noise or binding during steering input
Installation Notes and Tips
Verify hydraulic port thread sizes, mounting-hole spacing, input shaft dimensions, and OE reference numbers before installation. This part is for Chrysler PT Cruiser models with the listed power steering configurations, so confirm the vehicle’s steering setup and rack stamping before ordering. After installation, bleed the hydraulic system and perform a front-end alignment.
Quality Assurance
BBB Industries supplies remanufactured steering components for replacement service, and this rack and pinion is built to match the listed fitment and dimensional specifications for Chrysler PT Cruiser applications.
| Year | Make | Model | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2007 | Chrysler | PT Cruiser | Automatic | 2.4L | L4 | N/A | Power Steering; w/ Standard Steering (SBA), w/ OE No. 5272722AG; Reman Rack and Pinion |
| 2006 | Chrysler | PT Cruiser | Automatic | 2.4L | L4 | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2005 | Chrysler | PT Cruiser | Automatic | 2.4L | L4 | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2004 | Chrysler | PT Cruiser | Automatic | 2.4L | L4 | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2003 | Chrysler | PT Cruiser | Automatic | 2.4L | L4 | N/A | Power Steering; w/ 4656746AK Stamped on Rack; Reman Rack and Pinion |
