BBB Industries 102-0174 Rack and Pinion Assembly
| Brand | BBB Industries 102-0174 |
|---|---|
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 3.63 |
| Distance Between Mounting Holes (mm) | 92.202 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (In) | 1.75 |
| Input Shaft Length (mm) | 44.45 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M18X1.50 |
| Rack Length (In) | 47 |
| Rack Length (mm) | 1193.8 |
| Return Port Thread Size | M16X1.50 |
| Turns Lock To Lock | 2.813 |
| Product line | Reman Rack and Pinion |
| Fits | Chrysler and Dodge · 7 vehicles |
Remanufactured unit. A cost-conscious replacement for steering gear service.
Hydraulic design. Delivers responsive steering feel with fluid-assisted operation.
Inner tie rods included. Simplifies the job with key components already in place.
Cross-references 19320399 for the same application. See all 1.
Reman Rack and Pinion for Chrysler and Dodge
BBB Industries Reman Rack and Pinion 102-0174 is a hydraulic steering gear assembly built for direct replacement in select Chrysler and Dodge applications. It is remanufactured to match the original rack length, mounting layout, and port thread sizes needed for a proper steering system service.
This reman rack and pinion is compatible with 2008-2010 Chrysler PT Cruiser and 2004-2005 Dodge Neon equipped with power steering and standard steering (SBA). The BBB Industries Reman Rack and Pinion line focuses on remanufactured steering components for OE-style fit and function.
Key Features
- Part number: 102-0174
- Hydraulic rack and pinion assembly
- Remanufactured steering gear
- Inner tie rods included
- Rack length: 47 in. (1193.8 mm)
- Turns lock to lock: 2.813
- Input shaft diameter: 0.75 in. (19.05 mm)
- Pressure port thread size: M18x1.50
- Return port thread size: M16x1.50
- Two mounting holes with 3.63 in. (92.202 mm) spacing
Detailed Description
BBB Industries 102-0174 is a remanufactured hydraulic rack and pinion assembly engineered for steering replacement on the Chrysler PT Cruiser and Dodge Neon applications listed below. It includes inner tie rods and uses the specified input shaft dimensions, mounting-hole spacing, and hydraulic port thread sizes to support a correct OE-style installation. The rack measures 47 inches in length and provides 2.813 turns lock to lock, making it a direct-fit steering gear option for vehicles that require standard steering (SBA) with power steering.
This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application. Use BBB Industries 102-0174 when replacing a worn steering rack on a 2008-2010 Chrysler PT Cruiser or a 2004-2005 Dodge Neon with the matching steering configuration.
What It Helps Fix
- Steering play or looseness at the wheel
- Fluid leakage from the rack and pinion assembly
- Uneven or inconsistent steering response
- Excessive steering effort caused by internal wear
- Noise or binding from a worn hydraulic steering gear
Installation Notes and Tips
Verify the vehicle’s steering configuration, port sizes, and mounting-hole spacing before installation. Confirm that the application is power steering with standard steering (SBA) and compare the original rack dimensions to the replacement unit. Inspect tie rod ends, hydraulic lines, and related steering components during service to help ensure a complete repair.
- Fits 2008-2010 Chrysler PT Cruiser, N/A, Power Steering with Standard Steering (SBA); Reman Rack and Pinion
- Fits 2004-2005 Dodge Neon, N/A, Power Steering with Standard Steering (SBA); Reman Rack and Pinion
Quality Assurance
BBB Industries remanufactures steering components to meet application-specific replacement needs for Chrysler PT Cruiser and Dodge Neon service. Part number 102-0174 is built as a remanufactured hydraulic rack and pinion assembly for the listed fitments.
| Year | Make | Model | Submodel | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2010 | Chrysler | PT Cruiser | — | — | — | — | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2009 | Chrysler | PT Cruiser | — | Automatic | 2.4L | L4 | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2008 | Chrysler | PT Cruiser | — | Automatic | 2.4L | L4 | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2005 | Dodge | Neon | SE | Automatic | — | — | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2005 | Dodge | Neon | SXT | Automatic | — | — | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2004 | Dodge | Neon | SE | Automatic | — | — | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
| 2004 | Dodge | Neon | SXT | Automatic | — | — | N/A | Power Steering with Standard Steering (SBA); Reman Rack and Pinion |
