BBB Industries 102-0224 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 102-0224 is designed specifically for Jeep Grand Cherokee models. This remanufactured hydraulic rack and pinion unit includes essential components such as bushings and inner tie rods to ensure reliable steering performance.

• Remanufactured hydraulic rack and pinion assembly
• Includes bushings and inner tie rods for complete installation
• 22-inch (558.8 mm) distance between mounting holes with 2 mounting points
• Input shaft diameter of 0.75 inches (19.05 mm) and length of 1.625 inches (41.275 mm)
• Rack length of 52.75 inches (1339.85 mm) with 2.813 turns lock to lock
• Pressure port thread size M18x1.50 and return port thread size M16x1.50

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries offers remanufactured steering gear assemblies that meet OEM specifications. This product line focuses on restoring core components to factory standards, providing a cost-effective alternative to new parts while maintaining performance and durability. The 102-0224 part number is part of this line, ensuring compatibility and quality for Jeep Grand Cherokee vehicles requiring hydraulic steering systems.

Technical Description and Specifications

This rack and pinion assembly is engineered for hydraulic steering systems and features a 22-inch distance between mounting holes, accommodating Jeep Grand Cherokee chassis mounting points. The input shaft measures 0.75 inches in diameter and 1.625 inches in length, designed to fit the vehicle’s steering column interface precisely. The rack length of 52.75 inches allows for proper steering range, with 2.813 turns lock to lock for responsive handling. Included bushings and inner tie rods simplify installation and reduce the need for additional parts. The assembly uses M18x1.50 and M16x1.50 thread sizes for pressure and return ports, respectively, ensuring proper hydraulic line connections.

Common Applications and Problem Resolution

• Replacement for worn or leaking hydraulic rack and pinion units on Jeep Grand Cherokee
• Restores precise steering control and reduces play in the steering system
• Addresses issues with uneven steering response or difficulty turning
• Eliminates hydraulic fluid leaks from the steering gear assembly
• Improves vehicle handling and safety by restoring OEM steering geometry

Installation Notes and Tips

When installing the BBB Industries 102-0224 rack and pinion assembly, ensure the mounting holes align with the 22-inch spacing on the Jeep Grand Cherokee frame. Verify that the input shaft diameter and length match the steering column specifications. Use the included bushings and inner tie rods to complete the assembly and avoid sourcing additional components. Properly torque mounting bolts and connect hydraulic lines using the specified M18x1.50 and M16x1.50 thread sizes. After installation, bleed the hydraulic steering system to remove air and verify smooth steering operation.

Quality Assurance and Warranty Information

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards for fit, form, and function. The 102-0224 part number is backed by BBB Industries’ quality assurance processes, ensuring reliable performance in Jeep Grand Cherokee vehicles. Warranty coverage details should be confirmed at the point of purchase, typically including protection against defects in materials and workmanship.
