BBB Industries 102-0260 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 102-0260 is designed for precise steering control in Dodge Durango and Jeep Grand Cherokee models. This remanufactured hydraulic rack and pinion assembly includes inner tie rods and is engineered to meet OEM specifications for reliable performance.

• Remanufactured hydraulic rack and pinion assembly
• Compatible with Dodge Durango and Jeep Grand Cherokee
• Includes inner tie rods; outer tie rods and bushings not included
• Input shaft diameter: 0.712 inches (18.085 mm)
• Input shaft length: 4.25 inches (107.95 mm)
• Distance between mounting holes: 14.31 inches (363.474 mm)
• Rack length: 47 inches (1193.8 mm)
• Pressure port thread size: 18mm x 1.5
• Return port thread size: 16mm x 1.5
• Turns lock to lock: 3.687
• Two mounting holes for secure installation

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries offers remanufactured steering components that restore original steering feel and function. This product line focuses on hydraulic rack and pinion assemblies that are rebuilt to meet strict quality standards, providing a cost-effective alternative to new parts without compromising reliability. The 102-0260 part number is part of this line, ensuring compatibility and performance for select Dodge and Jeep vehicles.

Technical Description and Specifications

This remanufactured rack and pinion assembly features a hydraulic design suitable for power steering systems in Dodge Durango and Jeep Grand Cherokee models. The assembly includes inner tie rods but does not include bushings or outer tie rods, which may need to be sourced separately. The input shaft measures 0.712 inches in diameter and 4.25 inches in length, designed to fit the steering column interface precisely. The rack length of 47 inches and the 14.31-inch distance between mounting holes ensure proper fitment and mounting stability. Thread sizes for pressure and return ports are 18mm x 1.5 and 16mm x 1.5 respectively, matching OEM hydraulic line connections. The steering ratio is reflected in the 3.687 turns lock to lock, providing responsive steering control.

Common Applications and Problem Resolution

• Replacement for worn or leaking hydraulic rack and pinion assemblies
• Fixes excessive steering play or looseness in Dodge Durango and Jeep Grand Cherokee
• Addresses uneven or difficult steering effort due to internal rack wear
• Resolves fluid leaks from pressure or return ports in the steering gear
• Restores proper steering alignment and response after component failure

Installation Notes and Tips

• Verify compatibility with vehicle make, model, and year before installation
• Inspect and replace outer tie rods and bushings as needed since they are not included
• Ensure hydraulic lines match the 18mm x 1.5 pressure and 16mm x 1.5 return port threads
• Check mounting hole alignment using the 14.31-inch spacing for proper fit
• Bleed the power steering system thoroughly after installation to remove air

Quality Assurance and Warranty Information

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards for durability and performance. The 102-0260 part number is backed by BBB Industries' quality control processes, ensuring reliable operation in Dodge Durango and Jeep Grand Cherokee vehicles. Warranty coverage details should be confirmed with the distributor or installer, as BBB Industries typically offers limited warranties on remanufactured steering components.
