BBB Industries 103-0140P Rack and Pinion Assembly

Reman Rack and Pinion for 1996 Cadillac

BBB Industries 103-0140P is a remanufactured hydraulic rack and pinion assembly for select 1996 Cadillac DeVille, Eldorado, and Seville models with power steering and an EVO component. It is built for direct replacement service where precise steering response and correct hydraulic port sizing matter.

The BBB Industries Reman Rack and Pinion line focuses on remanufactured steering gear assemblies that match OE-style fitment and hydraulic configuration. Part number 103-0140P is a reman rack and pinion assembly with inner tie rods included, making it a practical choice for restoring steering feel on the Cadillac DeVille, Cadillac Eldorado, and Cadillac Seville.

• Remanufactured hydraulic rack and pinion assembly
• Fits 1996 Cadillac DeVille, N/A; power steering; supplied with EVO component
• Fits 1996 Cadillac Eldorado, N/A; power steering; supplied with EVO component
• Fits 1996 Cadillac Seville, N/A; power steering; supplied with EVO component
• Inner tie rods included; outer tie rods not included
• Rack length: 49.75 in. (1263.65 mm)
• Input shaft diameter: 0.688 in. (17.463 mm)
• Input shaft length: 1.875 in. (47.625 mm)
• Pressure and return ports: M16x1.50
• Turns lock to lock: 2.813

This part cross-references GM OE number 19320473 for the same application.

Use this rack and pinion assembly when the original steering gear shows internal wear, hydraulic leakage, excessive play, or inconsistent steering effort. It is also a direct replacement for vehicles with worn input shaft seals, damaged rack teeth, or steering response that no longer tracks smoothly.

• Steering fluid leakage from the rack housing or port connections
• Loose, wandering, or delayed steering response
• Noise or binding during steering input
• Wear in the hydraulic rack assembly affecting road feel
• Replacement needs on 1996 Cadillac DeVille, Eldorado, or Seville with power steering and EVO component

Installation should be performed with the correct hydraulic line fittings and verified against the vehicle’s steering configuration before removal of the original unit. Confirm port thread size, mounting hole spacing, and input shaft dimensions during installation to ensure proper alignment and hydraulic connection. Outer tie rods are not included, so existing components should be inspected and replaced as needed.

BBB Industries remanufactures steering components to meet application-specific fitment requirements for service replacement use. Part number 103-0140P is built for the listed Cadillac applications and should be matched to the vehicle’s power steering and EVO-equipped steering setup before installation.
