BBB Industries 103-0154 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 103-0154 is designed specifically for Pontiac Grand Prix models. This remanufactured hydraulic rack and pinion unit offers precise steering control and reliable performance tailored to your vehicle's specifications.

• Remanufactured hydraulic rack and pinion assembly
• Compatible with Pontiac Grand Prix
• Includes inner tie rods; outer tie rods not included
• Distance between mounting holes: 12.81 inches (325.374 mm)
• Input shaft diameter: 0.688 inches (17.463 mm), length: 1.75 inches (44.45 mm)
• Rack length: 48.75 inches (1238.25 mm)
• Pressure port thread size: M18x1.50; return port thread size: M16x1.50
• Turns lock to lock: 2.75
• Number of mounting holes: 2

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries focuses on remanufactured steering components that meet OEM specifications. This product line ensures that each rack and pinion assembly is rebuilt with precision to restore proper steering function and durability. The 103-0154 part number is part of this line, providing a cost-effective alternative to new units while maintaining quality and fitment for the Pontiac Grand Prix.

Technical Description and Specifications

This rack and pinion assembly features a hydraulic design suitable for vehicles equipped with hydraulic power steering systems. The input shaft measures 0.688 inches in diameter and 1.75 inches in length, designed to match the steering column interface of the Pontiac Grand Prix. The rack length of 48.75 inches ensures proper engagement with the vehicle’s steering linkage. The assembly includes inner tie rods but does not include bushings or outer tie rods, which may need to be sourced separately. Mounting is secured via two holes spaced 12.81 inches apart, and the unit features standard pressure and return port thread sizes (M18x1.50 and M16x1.50 respectively) for hydraulic connections.

Common Applications and Problem Resolution

• Restores steering precision and responsiveness in Pontiac Grand Prix vehicles
• Replaces worn or leaking hydraulic rack and pinion assemblies
• Addresses excessive play or looseness in steering
• Eliminates steering noise caused by damaged internal components
• Corrects uneven or difficult steering effort

Installation Notes and Tips

• Verify compatibility with your Pontiac Grand Prix model year before installation
• Inspect and replace outer tie rods and bushings if necessary, as they are not included
• Ensure hydraulic lines match the specified pressure and return port thread sizes
• Follow manufacturer torque specifications for mounting bolts and input shaft connections
• Bleed the power steering system thoroughly after installation to remove air

Quality Assurance and Warranty

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards for fit, form, and function. The 103-0154 part number is backed by BBB Industries’ quality control processes to ensure reliable performance. Warranty coverage details should be confirmed with the distributor or installer, as BBB Industries typically offers limited warranties on remanufactured steering components.
