BBB Industries 103-0165 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 103-0165 is designed specifically for Cadillac Seville models. This remanufactured hydraulic rack and pinion unit includes essential components such as bushings and inner tie rods to ensure reliable steering performance.

• Remanufactured hydraulic rack and pinion assembly
• Includes bushings and inner tie rods for complete installation
• Distance between mounting holes: 16.75 inches (425.45 mm)
• Input shaft diameter: 0.625 inches (15.875 mm), length: 1.125 inches (28.575 mm)
• Rack length: 50.5 inches (1282.7 mm)
• Pressure port thread size: M18x1.50; return port thread size: M16x1.50
• Two mounting holes with 2.438 turns lock to lock

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries offers remanufactured steering components that meet strict quality standards. This product line focuses on restoring original equipment specifications, providing a cost-effective alternative to new parts while maintaining reliable steering control. The 103-0165 assembly is part of this line, ensuring compatibility and performance for Cadillac Seville vehicles.

Technical Description and Specifications

This rack and pinion assembly features a hydraulic design tailored for Cadillac Seville models. The unit includes bushings and inner tie rods, but does not include outer tie rods. The input shaft measures 0.625 inches in diameter and 1.125 inches in length, designed to fit the vehicle’s steering column precisely. The rack length of 50.5 inches and mounting hole spacing of 16.75 inches ensure proper fitment. Thread sizes for pressure and return ports are M18x1.50 and M16x1.50 respectively, supporting hydraulic fluid connections. The assembly offers 2.438 turns lock to lock, providing responsive steering control.

Common Applications and Problem Resolution

• Replacement for worn or leaking hydraulic rack and pinion units on Cadillac Seville
• Restores steering precision and reduces play or looseness in the steering system
• Addresses issues with uneven steering response or difficulty turning
• Eliminates noise or vibration caused by damaged bushings or tie rods
• Improves overall vehicle handling and safety

Installation Notes and Tips

When installing the BBB Industries Reman Rack and Pinion Assembly 103-0165, ensure all hydraulic connections use the specified thread sizes (M18x1.50 for pressure port and M16x1.50 for return port). Verify the distance between mounting holes (16.75 inches) matches the vehicle’s mounting points. Since outer tie rods are not included, inspect and replace them separately if necessary. Proper alignment after installation is recommended to maintain steering accuracy and tire wear.

Quality Assurance and Warranty Information

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards. The 103-0165 part number is backed by BBB Industries’ quality control processes to ensure durability and performance. Warranty coverage details should be confirmed with the distributor or installer, as terms may vary.
