BBB Industries 103-0228 Rack and Pinion Assembly
| Brand | BBB Industries 103-0228 |
|---|---|
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 17.13 |
| Distance Between Mounting Holes (mm) | 435.102 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.687 |
| Input Shaft Diameter (mm) | 17.45 |
| Input Shaft Length (In) | 1.625 |
| Input Shaft Length (mm) | 41.275 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | 0.474 |
| Rack Length (In) | 38.75 |
| Rack Length (mm) | 984.25 |
| Return Port Thread Size | 0.436 |
| Turns Lock To Lock | 3.125 |
| Product line | Reman Rack and Pinion |
| Fits | Cadillac · 14 vehicles |
Remanufactured unit. A reman hydraulic steering gear assembly built for replacement use.
Inner tie rods included. Helps streamline steering gear replacement with a more complete assembly.
Hydraulic design. Uses the specified port and shaft dimensions for application-specific fitment.
Cross-references 19320524 and 22777702 for the same application. See all 2.
Overview
BBB Industries Reman Rack and Pinion 103-0228 is a hydraulic remanufactured steering gear assembly for select Cadillac CTS applications. It is built for vehicles with power steering and uses the specified mounting and port dimensions for proper replacement fitment.
This rack and pinion assembly includes inner tie rods and is identified by part number 103-0228. It cross-references 19320524 and 22777702 for the same application.
Key Features
- Remanufactured hydraulic rack and pinion assembly
- Inner tie rods included for a more complete steering gear replacement
- 3.125 turns lock to lock for steering response characteristics
- 38.75-inch rack length with 17.13-inch mounting hole spacing
- Fits Cadillac CTS power steering applications from 2008-2014
Detailed Description
BBB Industries 103-0228 is a remanufactured hydraulic rack and pinion assembly engineered for select Cadillac CTS models. Fitment covers 2008-2010 Cadillac CTS with power steering and no EVO component, plus 2012-2014 Cadillac CTS with power steering. The assembly uses a 0.687-inch input shaft diameter, 1.625-inch input shaft length, and the listed pressure and return port thread sizes for application-specific replacement.
As part of the Reman Rack and Pinion line, this unit focuses on steering gear replacement rather than a universal fit. The part number 103-0228 should be matched to the vehicle’s steering configuration and notes in the fitment data before installation.
What It Is Used For
- Replacing a worn or leaking steering rack
- Addressing steering play or inconsistent steering feel
- Restoring hydraulic steering operation
- Correcting noise or binding from the steering gear assembly
Installation Notes and Tips
Verify the vehicle’s steering system configuration before ordering. This part fits 2008-2010 Cadillac CTS, N/A, with power steering and no EVO component, and fits 2012-2014 Cadillac CTS, N/A, with power steering. Confirm mounting hole spacing, input shaft dimensions, and port thread sizes against the original unit. Part number 103-0228 should be matched to the application notes exactly.
Quality Assurance
BBB Industries supplies remanufactured steering components for replacement use. This remanufactured rack and pinion is built to match the listed application requirements for the Cadillac CTS.
| Year | Make | Model | Submodel | Body Type | Drive Type | Liters | Cylinders | Notes |
|---|---|---|---|---|---|---|---|---|
| 2014 | Cadillac | CTS | — | — | AWD | 3.0L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2014 | Cadillac | CTS | Base | — | AWD | 3.6L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2014 | Cadillac | CTS | Performance | Coupe | AWD | 3.6L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2014 | Cadillac | CTS | Performance | Wagon | AWD | 3.6L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2014 | Cadillac | CTS | Premium | Coupe | AWD | 3.6L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2014 | Cadillac | CTS | Premium | Wagon | AWD | 3.6L | V6 | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2013 | Cadillac | CTS | — | — | AWD | — | — | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2012 | Cadillac | CTS | — | — | AWD | — | — | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2010 | Cadillac | CTS | Base | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
| 2010 | Cadillac | CTS | Premium | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
| 2010 | Cadillac | CTS | Luxury | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
| 2010 | Cadillac | CTS | Performance | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
| 2009 | Cadillac | CTS | Base | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
| 2008 | Cadillac | CTS | — | — | AWD | — | — | Power Steering; Supplied w/o EVO Component; Reman Rack and Pinion |
