BBB Industries 103-0244 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 103-0244 is designed specifically for Cadillac CTS models requiring a reliable hydraulic steering component. This remanufactured rack and pinion assembly offers precise steering control and is engineered to meet OEM specifications for a direct replacement.

• Remanufactured hydraulic rack and pinion assembly
• Compatible with Cadillac CTS
• Includes inner tie rods; outer tie rods not included
• Distance between mounting holes: 21.5 inches (546.1 mm)
• Rack length: 48.875 inches (1241.425 mm)
• Input shaft diameter: 0.813 inches (20.638 mm)
• Input shaft length: 2.125 inches (53.975 mm)
• Pressure and return port thread size: 11mm
• Turns lock to lock: 2.938
• Number of mounting holes: 2

Detailed Product Description

This BBB Industries Reman Rack and Pinion Assembly (part number 103-0244) is a remanufactured hydraulic steering gear designed for Cadillac CTS vehicles. It features a rack length of 48.875 inches and a mounting hole distance of 21.5 inches, ensuring proper fitment and secure installation. The input shaft measures 0.813 inches in diameter and 2.125 inches in length, matching factory specifications for smooth steering input. The assembly includes inner tie rods for convenience, though outer tie rods are not included. Both pressure and return ports have an 11mm thread size, compatible with standard hydraulic steering lines. With 2.938 turns lock to lock, this rack and pinion assembly provides responsive steering performance consistent with Cadillac CTS requirements.

About the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries focuses on remanufactured steering components that meet or exceed OEM standards. These assemblies undergo thorough inspection and testing to restore functionality and durability. The 103-0244 model is part of this line, offering a cost-effective alternative to new parts while maintaining quality and fitment for Cadillac CTS vehicles.

Common Applications and Problem Resolution

• Restores precise steering response in Cadillac CTS models
• Replaces worn or leaking hydraulic rack and pinion assemblies
• Eliminates excessive play or steering wheel vibration
• Addresses fluid leaks from pressure or return ports
• Corrects uneven or difficult steering effort

Installation Notes and Tips

• Verify compatibility with your Cadillac CTS model year before installation
• Inspect and replace outer tie rods separately if needed, as they are not included
• Ensure hydraulic lines match the 11mm pressure and return port threads
• Follow manufacturer torque specifications for mounting bolts and input shaft
• Bleed the hydraulic steering system thoroughly after installation to remove air

Quality Assurance and Warranty

BBB Industries remanufactured rack and pinion assemblies undergo comprehensive testing to ensure reliable performance and durability. The 103-0244 part is built to meet OEM standards for fit and function. Warranty coverage details should be confirmed with the distributor or installer, as BBB Industries typically offers limited warranties on remanufactured steering components.
