BBB Industries 103-0291 Rack and Pinion Assembly

Reman Rack and Pinion for Cadillac SRX

BBB Industries Reman Rack and Pinion 103-0291 is a hydraulic steering gear assembly built for direct replacement in select Cadillac SRX applications. It is remanufactured with inner tie rods and bushings included, and it uses OE-style port and mounting dimensions for a precise steering system service.

Key Features

• Remanufactured hydraulic rack and pinion assembly
• Inner tie rods included; outer tie rods not included
• Bushings included for steering gear mounting support
• 18mm x 1.5 pressure port thread size and 16mm x 1.5 return port thread size
• 18.5 in mounting hole spacing and 51.75 in rack length
• 2.813 turns lock to lock for responsive steering feel
• Fits 2010-2016 Cadillac SRX, power steering, without Variable Assist Steering

Product Details

BBB Industries Reman Rack and Pinion 103-0291 is part of the BBB Industries Reman Rack and Pinion product line, which focuses on remanufactured steering components for OE-style service replacement. This hydraulic rack and pinion assembly is specified for 2010-2016 Cadillac SRX models with power steering and without Variable Assist Steering. The unit features a 14.249 mm input shaft diameter, 96.838 mm input shaft length, two mounting holes, and a 469.9 mm mounting hole distance to help match the original steering gear layout. This part cross-references OE number 15950145 for the same application.

Common Steering Issues This Part May Address

• Excessive steering play or looseness
• Fluid leakage from the steering gear
• Rough, inconsistent, or noisy steering operation
• Worn internal rack components affecting steering response
• Failure of the original hydraulic rack and pinion assembly

Installation Notes and Tips

Verify the vehicle is a 2010-2016 Cadillac SRX with power steering and without Variable Assist Steering before ordering. Confirm pressure and return port thread sizes, mounting hole spacing, and input shaft dimensions against the original unit during replacement. After installation, the hydraulic system should be properly bled and the front-end alignment checked to restore correct steering geometry.

Quality Assurance

This remanufactured steering gear is built by BBB Industries for replacement use in the Cadillac SRX platform. The remanufactured design supports OE-style fitment and serviceability for the specified application.
