BBB Industries 103-0293 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 103-0293 is designed specifically for Buick LaCrosse and Regal models. This remanufactured hydraulic rack and pinion unit offers precise steering control and reliable performance for your vehicle's steering system.

• Remanufactured hydraulic rack and pinion assembly
• Compatible with Buick LaCrosse and Regal
• Includes inner tie rods; outer tie rods not included
• Distance between mounting holes: 18.5 inches (469.9 mm)
• Rack length: 49 inches (1244.6 mm)
• Input shaft diameter: 0.66 inches (16.764 mm), length: 4 inches (101.6 mm)
• Pressure and return port thread size: 12mm
• Turns lock to lock: 2.625
• Two mounting holes for secure installation

Details on the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line from BBB Industries focuses on providing remanufactured steering components that meet OEM specifications. This product line ensures that each rack and pinion assembly undergoes thorough inspection and testing to restore functionality and durability. The 103-0293 part maintains hydraulic steering compatibility and includes inner tie rods to simplify installation for Buick LaCrosse and Regal vehicles.

Technical Description and Specifications

This remanufactured rack and pinion assembly features a hydraulic design suitable for power steering systems in Buick LaCrosse and Regal models. The assembly measures 49 inches in rack length with mounting holes spaced 18.5 inches apart, ensuring proper fitment. The input shaft diameter is 0.66 inches with a length of 4 inches, designed to match factory steering column connections. The unit includes inner tie rods but does not include bushings or outer tie rods. Both pressure and return ports have a 12mm thread size, compatible with standard hydraulic lines. The steering input offers 2.625 turns lock to lock, providing responsive steering feel.

Common Applications and Problem Resolution

• Restores precise steering response in Buick LaCrosse and Regal
• Replaces worn or leaking hydraulic rack and pinion assemblies
• Addresses excessive play or steering wheel vibration
• Eliminates fluid leaks from pressure or return ports
• Corrects uneven or difficult steering effort

Installation Notes and Tips

• Verify compatibility with Buick LaCrosse or Regal before installation
• Ensure hydraulic lines match 12mm thread size for pressure and return ports
• Inspect and replace outer tie rods separately if needed
• Check mounting hole alignment (18.5 inches apart) for proper fit
• Bleed the power steering system after installation to remove air

Quality Assurance and Warranty

BBB Industries remanufactured rack and pinion assemblies undergo comprehensive testing to meet OEM standards for performance and durability. The 103-0293 part is built to restore steering function reliably. Warranty coverage details should be confirmed at the point of purchase, as BBB Industries typically offers limited warranties on remanufactured steering components.
