BBB Industries 103-0303 Rack and Pinion Assembly

Reman Rack and Pinion for Equinox and Terrain

BBB Industries Reman Rack and Pinion 103-0303 is a hydraulic steering gear assembly built for direct replacement in select Chevrolet Equinox and GMC Terrain applications. It is remanufactured to match the original rack-and-pinion layout and includes inner tie rods and bushings for a service-ready steering repair.

Key Features

• Remanufactured hydraulic rack and pinion assembly
• Includes inner tie rods and bushings
• Input shaft diameter: 0.688 in. (17.463 mm)
• Input shaft length: 1.813 in. (46.038 mm)
• Rack length: 48.125 in. (1222.375 mm)
• Distance between mounting holes: 18 in. (457.2 mm)
• Pressure port thread size: M18x1.50
• Return port thread size: M16x1.50
• Turns lock to lock: 2.75
• Compatible with 2010-2017 Chevrolet Equinox and 2010-2017 GMC Terrain with 19" wheels and hydraulic power steering

Product Details

BBB Industries 103-0303 is part of the Reman Rack and Pinion line, a product line focused on remanufactured steering gear assemblies for OE-style replacement needs. This unit is built for hydraulic steering systems and matches the original mounting and port configuration used on the listed vehicles. It cross-references OE part numbers 19327623 and 20845543 for the same application.

Fits 2010-2017 Chevrolet Equinox, N/A; power steering; with 19" wheels; hydraulic steering. Fits 2010-2017 GMC Terrain, N/A; power steering; with 19" wheels; hydraulic steering. The BBB Industries 103-0303 rack and pinion is a direct-fit option for these vehicle-specific steering repairs.

Common Repair Applications

• Steering play or looseness in the wheel
• Fluid leakage from the hydraulic rack assembly
• Hard steering or inconsistent steering response
• Excessive noise from worn internal steering components
• Restoring proper steering feel after rack wear

Installation Notes

Verify hydraulic line thread sizes, mounting-hole spacing, and input shaft dimensions before installation. This assembly uses two mounting holes and includes inner tie rods, while outer tie rods are not included. Always confirm vehicle configuration, including 19" wheels and hydraulic steering, against the fitment data before replacement. After installation, perform a full alignment and bleed the hydraulic steering system according to service procedures.

Quality Assurance

This remanufactured steering assembly is built to replace the original rack and pinion used in the listed Chevrolet Equinox and GMC Terrain applications. BBB Industries remanufactured steering components are produced for OE-style fit and function in service repairs.
