OE Quality
60-Day Returns
BBB Industries 13547 Alternator
Reman Alternator for Toyota Supra and Lexus SC300
BBB Industries REMAN ALTERNATOR Part Number 13547 is a 12-volt, 100-amp replacement alternator built for select Toyota and Lexus applications. It uses an internal voltage regulator, internal fan, and air cooling with a conventional pulley setup for serpentine belt systems.
Key Features
- 100 amp amperage rating for OE-style charging output
- 12V alternator with internal voltage regulator
- Air-cooled design with internal fan
- Conventional pulley included, 6-groove serpentine belt type
- Clockwise rotation and negative polarity
- OE manufacturer reference: Nippondenso
- Plug clock position: 12
- Outside pulley diameter: 2-7/16 in. (62 mm)
Detailed Description
This BBB Industries REMAN ALTERNATOR is engineered for direct replacement in applications originally equipped with a Nippondenso-style charging system. Part Number 13547 is listed for 1993-1998 Toyota Supra with Twin Turbo and 100 amps, as well as 1995 Lexus SC300 with a threaded boss hole on the side of the alternator and 100 amps. This part cross-references Toyota and Denso numbers such as 27060-46120 and 101211-7020 for the same application. For buyers searching for a 1993-1998 Toyota Supra alternator or a 1995 Lexus SC300 reman alternator, this unit matches the specified electrical and pulley configuration details.
What This Alternator Helps Address
- Battery warning light caused by charging system failure
- Low system voltage during driving or idle
- Dim lights or unstable electrical performance
- Alternator bearing or internal regulator wear
- Charging output loss on Toyota Supra and Lexus SC300 applications
Installation Notes and Tips
Verify the vehicle’s original alternator uses a 12-volt, 100-amp Nippondenso-style setup with a 6-groove serpentine pulley, clockwise rotation, and 12 o’clock plug position before installation. Confirm the Lexus SC300 side boss-hole configuration and the Toyota Supra Twin Turbo application details against the removed unit. Inspect belt condition, pulley alignment, and charging connections during replacement to help ensure proper operation.
Quality Assurance
BBB Industries remanufactured electrical components are built to meet application-specific replacement requirements for charging system service. Part Number 13547 is a remanufactured alternator designed around the listed OE-style specifications for the confirmed fitments.
| Brand | BBB Industries |
|---|---|
| Part Number | 13547 |
| Position | REMAN ALTERNATOR |
| Amperage Rating | 100 |
| AC Tap | No |
| Brushless Design | No |
| Cooling Method | Air |
| Decoupled Or Clutch Pulley | No |
| Fan Type | Internal |
| Number Of Pulley Grooves | 6 |
| OE Manufacturer | Nippondenso |
| One Wire Capable | No |
| Outside Pulley Diameter (in) | 2-7/16 |
| Outside Pulley Diameter (mm) | 62 |
| Plug Clock Position | 12 |
| Polarity | Negative |
| Pulley Belt Type | Serpentine |
| Pulley Included | Yes |
| Pulley Type | Conventional |
| Rotation Direction | Clockwise |
| Voltage (V) | 12 |
| Voltage Regulator Type | Internal |
This part fits 7 vehicles. Search below:
| Year | Make | Model | Transmission | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 1998 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
| 1997 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
| 1996 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
| 1995 | Lexus | SC300 | 3.0L | L6 | N/A | w/Threaded Boss Hole on Side of Alt; 100 Amps; REMAN ALTERNATOR | |
| 1995 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
| 1994 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
| 1993 | Toyota | Supra | Automatic | 3.0L | L6 | N/A | w/Twin Turbo; 100 Amps; REMAN ALTERNATOR |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
