BBB Industries 201-0138E Rack and Pinion Assembly
| Brand | BBB Industries 201-0138E |
|---|---|
| Connector A Pin Count | 2 pin |
| Connector B Pin Count | 3 pin |
| Control Module Included | Yes |
| Hydraulic or Electric | Electric |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.88 |
| Input Shaft Diameter (mm) | 22.352 |
| Input Shaft Length (In) | 2.38 |
| Input Shaft Length (mm) | 60.452 |
| Motor Included | Yes |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Rack Length (In) | 54.5 |
| Rack Length (mm) | 1384.3 |
| Turns Lock To Lock | 2.62 |
| Product line | Reman Rack and Pinion |
| Fits | Ford · 5 vehicles |
Remanufactured assembly. Restored for dependable steering performance.
Electric design. Includes the motor and control module.
Complete rack and pinion. Inner tie rods are included for a fuller repair.
Cross-references DR3Z-3504-CE for the same application. See all 1.
Reman Rack and Pinion for Mustang
BBB Industries 201-0138E is a remanufactured electric rack and pinion assembly for select 2011-2014 Ford Mustang models with power steering and 19-inch or 20-inch wheels. It includes the motor, control module, inner tie rods, and the rack assembly needed for a direct steering system replacement.
Key Features
- Remanufactured electric rack and pinion assembly
- Includes motor and control module
- Inner tie rods included; outer tie rods not included
- 2-pin Connector A and 3-pin Connector B
- Input shaft diameter: 0.88 in. (22.352 mm)
- Input shaft length: 2.38 in. (60.452 mm)
- Rack length: 54.5 in. (1384.3 mm)
- 2.62 turns lock to lock
- 2 mounting holes
Detailed Description
BBB Industries Reman Rack and Pinion line focuses on remanufactured steering components built for OE-style replacement needs. Part number 201-0138E is an electric rack and pinion assembly for the Ford Mustang, with the motor and control module already included for applications that use electronic power steering. This unit cross-references Ford DR3Z-3504-CE for the same application.
Compatible With 2011-2014 Ford Mustang, power steering models with 19-inch or 20-inch wheels and electronic rack configuration. Use this BBB Industries 201-0138E when replacing a worn or failing steering rack on the Mustang platform and when the vehicle requires a remanufactured electric rack assembly with integrated electronics.
What It Can Help Resolve
- Excessive steering play or looseness
- Uneven or inconsistent steering response
- Noise from a worn electric rack assembly
- Steering assist faults related to the rack, motor, or control module
- Leak-free replacement for a failing steering gear assembly
Installation Notes and Tips
Fits 2011-2014 Ford Mustang, N/A, with power steering, 19-inch or 20-inch wheels, and an electronic rack. The OE service manual calls for Programmable Module Installation (PMI) or an As-Built program after installation. Verify connector pin counts, input shaft dimensions, and mounting points before installation. Outer tie rods are not included, so reuse or replace them as needed based on condition.
Quality Assurance
This remanufactured BBB Industries steering rack is built as a replacement assembly for the specified Mustang applications and is intended to meet the dimensional and electronic requirements of the OE-style setup.
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 2014 | Ford | Mustang | — | Power Steering; w/ 19" or 20" Wheels (Electronic Rack); Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion |
| 2013 | Ford | Mustang | — | Power Steering; w/ 19" or 20" Wheels (Electronic Rack); Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion |
| 2012 | Ford | Mustang | — | Power Steering; w/ 19" or 20" Wheels (Electronic Rack); Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion |
| 2011 | Ford | Mustang | Base | Power Steering; w/ 19" or 20" Wheels (Electronic Rack); Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion |
| 2011 | Ford | Mustang | GT | Power Steering; w/ 19" or 20" Wheels (Electronic Rack); Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion |
