BBB Industries 201-0151E Rack and Pinion Assembly

Reman Rack and Pinion for Ford Steering Repair

BBB Industries Reman Rack and Pinion 201-0151E is a remanufactured electric steering rack and pinion assembly built for Ford applications that require programmable module installation. It is a direct-fit steering gear replacement for select Ford Focus and Ford C-Max models with electric power steering.

Key Features

• Remanufactured electric rack and pinion assembly
• Control module included for steering system integration
• Motor included
• Inner tie rods included
• 2-pin connector A and 3-pin connector B
• 3 mounting holes
• Rack length: 50.88 in. (1292.352 mm)
• Turns lock to lock: 2.25
• Input shaft diameter: 0.72 in. (18.288 mm)
• Input shaft length: 3.88 in. (98.552 mm)

Product Details

BBB Industries Reman Rack and Pinion 201-0151E is part of the Reman Rack and Pinion line, a remanufactured steering component range focused on restoring OE-style steering function for vehicles with electric assist systems. This assembly is built for select 2012-2018 Ford Focus models with 18-inch wheels, plus 2013-2016 Ford C-Max applications listed below. The unit includes the motor, control module, and inner tie rods, while outer tie rods are not included.

This part cross-references Monroe Shocks & Struts (e.g., CV6Z-3504-C, CV6Z-3504-CE) for the same application. Use part number 201-0151E when matching steering rack specifications, connector count, and vehicle fitment.

Vehicle Fitment

• Fits 2012-2018 Ford Focus, N/A — Power Steering; w/ 18" Wheels; Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion
• Fits 2016 Ford C-Max, N/A — Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion
• Fits 2013-2015 Ford C-Max, N/A — Power Steering; Requires Programmable Module Installation (PMI) per OE service manual or complete an As-Built program; Reman Rack and Pinion

Common Steering Issues Addressed

• Excessive steering play or loose steering feel
• Electric power steering faults tied to rack and pinion wear
• Noise or binding during steering input
• Incorrect steering response after rack failure
• Leak-free replacement for worn steering gear assemblies

Installation Notes

Confirm connector pin counts, mounting points, and input shaft dimensions before installation. This electric rack requires Programmable Module Installation (PMI) per the OE service manual or a complete As-Built program on the listed Ford Focus and Ford C-Max applications. Outer tie rods are not included, so verify whether existing components meet service requirements before beginning the repair.

Quality Assurance

BBB Industries remanufactures steering components to restore proper operation and fitment consistency for service replacement use. Verify all vehicle-specific programming and calibration steps are completed after installation to ensure correct steering system operation.
