BBB Industries 201-0156E Rack and Pinion Assembly

Overview

This remanufactured electric rack and pinion assembly is built for steering systems that use an integrated motor and control module. BBB Industries 201-0156E is a direct-fit steering gear replacement for select Ford applications, with inner tie rods included and OE-style electronic connections.

Key Features

• Remanufactured electric rack and pinion assembly for electronic power steering systems.
• Integrated motor and control module included for a complete steering gear unit.
• Inner tie rods included; outer tie rods are not included.
• Two mounting holes and OE-style 2-pin and 3-pin connectors.
• Rack length measures 54.75 inches with 2.38 turns lock to lock.
• Part number 201-0156E for fitment verification and ordering.

Detailed Description

BBB Industries 201-0156E is a reman rack and pinion assembly engineered for electric steering systems that require integrated electronic control. The unit uses a 0.73-inch input shaft diameter, a 2.38-inch input shaft length, and a two-hole mounting layout to match the original steering gear configuration. With inner tie rods included and outer tie rods excluded, it is set up as a steering gear replacement rather than a complete tie rod service kit.

This part fits 2013 Ford Explorer, N/A, with power steering and automated parking system notes, and 2013 Ford Police Interceptor Utility, N/A. Use part number 201-0156E when confirming application details, especially where programmable module installation or as-built programming is required by the OE service procedure. This part cross-references Ford OE numbers DB5Z-3504-D and DB53-3D080-BF for the same application.

Common Uses

• Restores steering response when the rack and pinion assembly has internal wear.
• Addresses electronic steering faults tied to the motor or control module.
• Replaces a leaking or binding steering gear assembly.
• Corrects excessive steering play or inconsistent assist.
• Supports repair of steering systems with OE electronic connector requirements.

Installation Notes

Verify connector pin count, rack length, and mounting layout before installation. This application requires programmable module installation (PMI) per the OE service manual or completion of an as-built program where specified. Follow factory steering alignment and calibration procedures after installation.

Quality Assurance

BBB Industries supplies remanufactured steering components built to match OE-style fitment and electronic integration requirements. Part number 201-0156E is intended for direct replacement use on the listed applications.
