BBB Industries 203-0129E Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion Assembly

The BBB Industries Reman Rack and Pinion Assembly 203-0129E is designed specifically for Buick and Chevrolet vehicles, including the Cruze and Verano models. This remanufactured electric rack and pinion assembly offers a reliable steering solution with included inner tie rods and motor for a comprehensive replacement.

• Remanufactured electric rack and pinion assembly
• Compatible with Buick Cruze and Chevrolet Verano
• Includes inner tie rods and motor
• Input shaft diameter: 0.745 inches (18.923 mm)
• Input shaft length: 3.94 inches (100.076 mm)
• Rack length: 47.5 inches (1206.5 mm)
• Turns lock to lock: 2.75
• Connectors: 2-pin, 3-pin, and 5-pin configurations
• Two mounting holes for secure installation

Detailed Product Description

The BBB Industries Reman Rack and Pinion Assembly 203-0129E is a remanufactured steering gear designed for electric power steering systems. It features a 0.745-inch diameter input shaft with a length of 3.94 inches, providing precise steering input transfer. The rack length measures 47.5 inches, suitable for the specified Buick and Chevrolet models. This assembly includes the motor and inner tie rods, but outer tie rods and control module are not included. The unit has three connectors with 2-pin, 3-pin, and 5-pin configurations to ensure proper electrical connections. With 2 mounting holes and a lock-to-lock turn ratio of 2.75, this rack and pinion assembly offers a balance of responsiveness and control for the Cruze and Verano.

About the Reman Rack and Pinion Product Line

BBB Industries' Reman Rack and Pinion product line focuses on remanufactured steering components that meet OEM specifications. These assemblies are rebuilt to restore functionality and durability while providing a cost-effective alternative to new parts. The 203-0129E model is part of this line, offering a remanufactured electric rack and pinion solution with included motor and inner tie rods, designed to fit specific Buick and Chevrolet vehicles.

Common Applications and Problem Resolution

• Replaces worn or leaking rack and pinion assemblies in Buick Cruze and Chevrolet Verano
• Addresses steering play or looseness issues
• Restores electric power steering functionality
• Eliminates noise or binding during steering
• Corrects uneven or difficult steering response

Installation Notes and Tips

• Ensure compatibility with Buick Cruze or Chevrolet Verano before installation
• Verify electrical connector pin counts (2-pin, 3-pin, 5-pin) match vehicle harness
• Inspect input shaft dimensions for proper fit
• Use proper torque specifications on mounting bolts
• Bleed the power steering system as required after installation

Quality Assurance and Warranty

This remanufactured rack and pinion assembly undergoes thorough inspection and testing to meet performance standards. While specific warranty details are not provided here, BBB Industries typically offers limited warranties on remanufactured steering components to ensure reliability and customer confidence.
