OE Quality
60-Day Returns
BBB Industries 208-0111E Rack and Pinion Assembly
Remanufactured Electric Rack and Pinion for Mazda RX-8
BBB Industries 208-0111E is a remanufactured electric rack and pinion assembly for select 2004-2011 Mazda RX-8 models with power steering. It includes inner tie rods and a motor, and it is built for direct replacement service in steering systems that require precise rack travel and torque sensor recalibration after installation.
Key Features
- Remanufactured rack and pinion assembly from BBB Industries Reman Rack and Pinion
- Fits 2004-2011 Mazda RX-8, power steering applications
- Electric steering design with motor included
- Inner tie rods included for a complete steering gear replacement
- 3-pin Connector A and 2-pin Connector B
- Rack length: 46.880 in. (1190.752 mm)
- Turns lock to lock: 2.940
- Input shaft diameter: 0.690 in. (17.526 mm)
- Input shaft length: 1.880 in. (47.752 mm)
Product Details
BBB Industries 208-0111E is part of the Reman Rack and Pinion line, a product line focused on remanufactured steering gear assemblies for service replacement. This unit is engineered for the Mazda RX-8 electric power steering setup and matches the listed connector and shaft specifications for proper integration. For this application, a recalibration of the torque sensor neutral position is required after installation. This part cross-references Monroe Shocks & Struts (e.g., FE01-32-110D) for the same application.
Common Steering Issues It Can Address
- Excessive steering play or looseness in the rack assembly
- Uneven or inconsistent steering response
- Noise or binding from a worn electric rack and pinion unit
- Power steering performance problems tied to internal rack wear
- Failure of the original steering gear assembly on Mazda RX-8 models
Installation Notes and Tips
Verify connector pin counts, input shaft dimensions, and rack length before installation. This assembly is listed for 2004-2011 Mazda RX-8 models with power steering, and the torque sensor neutral position must be recalibrated after the unit is installed. Confirm steering system condition and alignment settings during replacement to support proper operation.
Quality Assurance
BBB Industries remanufactured steering components are processed as service replacement parts and built to match the listed application details for the Mazda RX-8. Part number 208-0111E should be matched to the vehicle’s steering configuration and connector layout before installation.
| Brand | BBB Industries |
|---|---|
| Part Number | 208-0111E |
| Position | Reman Rack and Pinion |
| Connector A Pin Count | 3 pin |
| Connector B Pin Count | 2 pin |
| Control Module Included | No |
| Hydraulic or Electric | Electric |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.690 |
| Input Shaft Diameter (mm) | 17.526 |
| Input Shaft Length (In) | 1.880 |
| Input Shaft Length (mm) | 47.752 |
| Motor Included | Yes |
| New or Remanufactured | Remanufactured |
| Rack Length (In) | 46.880 |
| Rack Length (mm) | 1190.752 |
| Turns Lock To Lock | 2.940 |
This part fits 8 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2011 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2010 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2009 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2008 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2007 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2006 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2005 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
| 2004 | Mazda | RX-8 | N/A | Power Steering; A recalibration of the torque sensor Nuetral position is required.; Reman Rack and Pinion |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
