BBB Industries 210-0129 Rack and Pinion Assembly
| Brand | BBB Industries 210-0129 |
|---|---|
| Bushings Included | Yes |
| Check Valve | No |
| Distance Between Mounting Holes (In) | 18.438 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rod Length | 9.5 |
| Inner Tie Rod Thread Size | 2.73 |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.678 |
| Input Shaft Diameter (mm) | 17.23 |
| Input Shaft Length (In) | 5.063 |
| Input Shaft Length (mm) | 128.588 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Orientation (Center) | 7:00 to 7:30 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | Not applicable |
| Rack Length (In) | 41.813 |
| Rack Length (mm) | 1062.038 |
| Return Port Thread Size | Not applicable |
| Sensor Included | No |
| Turns Lock To Lock | 2.938 |
| Product line | Reman Rack and Pinion |
| Fits | Nissan · 14 vehicles |
Remanufactured unit. Restored to deliver dependable steering performance.
Hydraulic design. Provides smooth, responsive steering control.
Inner tie rods included. Simplifies replacement with key components already in place.
Cross-references 48001-3BA0A, 48001-9KA0A and 48001-9MD0A for the same application. See all 3.
Reman Rack and Pinion for Nissan Versa
BBB Industries Reman Rack and Pinion 210-0129 is a hydraulic steering gear assembly built for direct replacement in select Nissan Versa and Nissan Versa Note applications. It is remanufactured to restore steering response, with inner tie rods included and bushings already in place for a cleaner service replacement.
Compatible With 2012-2018 Nissan Versa, 2014-2018 Nissan Versa Note, and 2019 Nissan Versa and Versa Note applications with electronic steering notes listed below. This BBB Industries Reman Rack and Pinion 210-0129 also cross-references OE part numbers 48001-3BA0A and 48001-9KA0A for the same application.
Key Features
- Remanufactured hydraulic rack and pinion assembly
- Inner tie rods included; outer tie rods not included
- Bushings included for replacement convenience
- 2 mounting holes with 18.438 in. mounting-hole spacing
- Input shaft diameter: 0.678 in. / 17.23 mm
- Input shaft length: 5.063 in. / 128.588 mm
- Rack length: 41.813 in. / 1062.038 mm
- Turns lock to lock: 2.938
- Center orientation: 7:00 to 7:30
Product Details
BBB Industries Reman Rack and Pinion 210-0129 is part of the Reman Rack and Pinion line, a product line focused on remanufactured steering gear replacements for service applications. This assembly is hydraulic, uses a two-hole mounting layout, and does not use a sensor, check valve, or pressure/return port thread sizing in this application. The included inner tie rods and bushings support a more complete steering gear replacement on the listed Nissan Versa and Versa Note models.
Fits 2019 Nissan Versa, N/A, Electronic Steering; Reman Rack and Pinion. Fits 2019 Nissan Versa Note, N/A, Electronic Steering; Reman Rack and Pinion. Fits 2012-2018 Nissan Versa, N/A, Power Steering; Electronic Steering; Reman Rack and Pinion. Fits 2014-2018 Nissan Versa Note, N/A, Power Steering; Electronic Steering; Reman Rack and Pinion. Use BBB Industries 210-0129 when replacing the steering rack on these Nissan Versa and Nissan Versa Note applications.
What It Helps Address
- Loose or inconsistent steering feel
- Steering gear leakage from a worn rack assembly
- Excessive play in the steering system
- Noisy or worn steering rack operation
- Restoration of steering response after rack wear
Installation Notes and Tips
Verify the vehicle’s steering configuration, mounting-hole spacing, input shaft dimensions, and lock-to-lock specification before installation. Because this assembly is hydraulic and uses included inner tie rods, confirm that the existing steering lines and related components match the application requirements. A professional alignment is recommended after steering gear replacement.
Quality Assurance
BBB Industries remanufactured steering components are processed as service replacements for OE-style fit and function on the listed applications. Part number 210-0129 is built for the specified Nissan Versa and Versa Note fitments and is identified by the interchange references listed above.
| Year | Make | Model | Liters | Cylinders | Notes |
|---|---|---|---|---|---|
| 2019 | Nissan | Versa | — | — | Electronic Steering; Reman Rack and Pinion |
| 2019 | Nissan | Versa Note | — | — | Electronic Steering; Reman Rack and Pinion |
| 2018 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2018 | Nissan | Versa Note | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2017 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2017 | Nissan | Versa Note | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2016 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2016 | Nissan | Versa Note | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2015 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2015 | Nissan | Versa Note | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2014 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2014 | Nissan | Versa Note | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2013 | Nissan | Versa | — | — | Power Steering; Electronic Steering; Reman Rack and Pinion |
| 2012 | Nissan | Versa | 1.6L | L4 | Power Steering; Electronic Steering; Reman Rack and Pinion |
