BBB Industries 305-0133 Rack and Pinion Assembly

Overview of BBB Industries Reman Rack and Pinion 305-0133

The BBB Industries Reman Rack and Pinion Assembly 305-0133 is designed for precise steering control in select Acura and Honda vehicles. This remanufactured hydraulic rack and pinion unit includes essential components to ensure reliable performance and fitment for models like the Honda Accord and Acura CL.

• Remanufactured hydraulic rack and pinion assembly
• Includes bushings and inner tie rods for complete installation
• Distance between mounting holes: 4.25 inches (107.95 mm)
• Input shaft diameter: 0.687 inches (17.46 mm), length: 1.75 inches (44.45 mm)
• Rack length: 42 inches (1066.8 mm) with 3.125 turns lock to lock
• Pressure and return port thread size: M16x1.50
• Compatible with Acura and Honda models including Accord and CL

Detailed Product Description

This remanufactured rack and pinion assembly from BBB Industries is engineered to meet the specifications required for hydraulic steering systems in Acura and Honda vehicles. The 305-0133 part number features a rack length of 42 inches and a precise input shaft diameter and length to match OEM standards. The assembly includes bushings and inner tie rods, facilitating a more straightforward installation process. With two mounting holes spaced 4.25 inches apart, this rack and pinion ensures a secure fit. The hydraulic design incorporates M16x1.50 thread sizes for both pressure and return ports, supporting proper fluid flow and steering responsiveness.

About the Reman Rack and Pinion Product Line

The Reman Rack and Pinion line by BBB Industries focuses on providing remanufactured steering components that restore vehicle steering performance to factory specifications. This product line emphasizes quality rebuilding processes, including the replacement of wear items such as bushings and tie rods, to extend the service life of the steering assembly. The 305-0133 model is part of this line, offering a cost-effective alternative to new units while maintaining compatibility and reliability for Acura and Honda vehicles.

Common Applications and Problem Resolution

• Replaces worn or leaking hydraulic rack and pinion assemblies
• Addresses steering play or looseness in Acura Accord and Honda CL models
• Corrects uneven or difficult steering response
• Eliminates noise or vibration caused by damaged bushings or inner tie rods
• Restores proper steering geometry and control

Installation Notes and Tips

• Verify compatibility with vehicle make, model, and year before installation
• Inspect and replace outer tie rods separately, as they are not included
• Ensure hydraulic lines match M16x1.50 thread size for pressure and return ports
• Check mounting hole alignment using the 4.25-inch spacing for proper fit
• Bleed the hydraulic steering system thoroughly after installation to remove air

Quality Assurance and Warranty

BBB Industries remanufactured rack and pinion assemblies undergo rigorous testing to meet OEM standards. The 305-0133 part number is rebuilt with precision components including new bushings and inner tie rods to ensure durability and performance. While specific warranty details may vary, BBB Industries typically offers limited warranties covering defects in materials and workmanship for remanufactured steering components.
