BBB Industries 305-0164 Rack and Pinion Assembly

Reman Rack and Pinion for Acura RL

BBB Industries 305-0164 is a remanufactured hydraulic rack and pinion assembly for 2005-2006 Acura RL models equipped with power steering. It is built for direct steering system replacement and includes inner tie rods and bushings for a service-ready fit.

As part of BBB Industries’ Reman Rack and Pinion line, this assembly is remanufactured to restore steering response in applications that require a hydraulic rack. The 305-0164 is a fitment-specific replacement for Acura RL steering service and cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Key Features

• Fits 2005-2006 Acura RL, power steering applications
• Hydraulic rack and pinion assembly
• Remanufactured unit for steering system replacement
• Inner tie rods included
• Bushings included
• 4 mounting holes with 14.38 in. mounting-hole spacing
• Input shaft diameter: 0.616 in.; input shaft length: 2.625 in.
• Pressure port thread size: M14x1.50
• Return port thread size: M16x1.50
• Rack length: 43.125 in.; 3 turns lock to lock

Detailed Description

BBB Industries 305-0164 reman rack and pinion assembly is engineered for the steering layout used in 2005-2006 Acura RL vehicles with hydraulic power steering. The assembly includes inner tie rods and bushings, helping simplify steering gear replacement on the Acura RL while matching the original hydraulic port and mounting specifications. With a 43.125-inch rack length, 4 mounting holes, and 3 turns lock to lock, this unit is built around the dimensions needed for a direct steering gear service replacement.

Use this BBB Industries remanufactured rack and pinion when replacing a worn steering gear on Acura RL models from 2005 and 2006. The 305-0164 part number is also useful for catalog matching and interchange lookup during steering repair planning.

What It Helps Fix

• Excessive steering play or loose steering feel
• Fluid leakage from a worn hydraulic rack and pinion
• Uneven or inconsistent steering response
• Noise or binding from a deteriorated steering gear
• Restoration of steering control after rack wear

Installation Notes and Tips

Verify hydraulic port thread sizes, mounting-hole spacing, and input shaft dimensions before installation. This rack and pinion is for Acura RL vehicles equipped with power steering, so confirm the vehicle’s steering system configuration before ordering. After installation, perform a full alignment and inspect the hydraulic system for leaks, proper fluid condition, and secure line connections.

Quality Assurance

BBB Industries remanufactures steering components to meet application-specific replacement needs. This reman rack and pinion is built for the confirmed 2005-2006 Acura RL fitment and follows the dimensional and connection requirements listed for the part.
