BBB Industries 311-0114 Rack and Pinion Assembly
BBB Industries Reman Rack and Pinion for Toyota Solara
Restore steering response with this BBB Industries remanufactured rack and pinion assembly for the 1999-2003 Toyota Solara. Part number 311-0114 is a hydraulic steering gear built for vehicles equipped with power steering, with inner tie rods and bushings included for a complete replacement assembly.
Key Features
- Remanufactured hydraulic rack and pinion assembly
- Fits 1999-2003 Toyota Solara with power steering
- Inner tie rods included; outer tie rods not included
- Bushings included
- Input shaft diameter: 0.75 in. (19.05 mm)
- Pressure port thread size: M16x1.50
- Return port thread size: M17x1.50
- Rack length: 51.25 in. (1301.75 mm)
- Turns lock to lock: 2.875
Product Details
BBB Industries Reman Rack and Pinion line focuses on remanufactured steering components built to replace worn hydraulic steering gears with a direct-fit service part. This 311-0114 rack and pinion assembly is specified for Toyota Solara applications from 1999 through 2003 and is identified by part number 311-0114 for ordering and cross-reference use. This part cross-references Monroe Shocks & Struts (e.g., 19320959) for the same application.
For Toyota Solara steering repair, this assembly addresses hydraulic steering systems that show play, leakage, or inconsistent steering effort. The included inner tie rods and bushings support a more complete steering gear replacement on the specified Toyota Solara model years.
Common Issues This Part Can Address
- Steering wheel play or looseness
- Hydraulic fluid leakage from the steering gear
- Uneven or inconsistent steering effort
- Clunking or knocking from the steering rack area
- Worn inner tie rods affecting steering precision
Installation Notes and Tips
Fits 1999-2003 Toyota Solara, N/A. Confirm hydraulic port thread sizes, input shaft dimensions, and steering system configuration before installation. Inspect related steering components, alignment settings, and fluid condition during replacement. Part number 311-0114 should be matched to the vehicle application before service begins.
Quality Assurance
This remanufactured steering rack is built as a service replacement for the listed Toyota Solara applications and is identified by BBB Industries part number 311-0114. Verify fitment against the vehicle’s steering system and OE specifications before installation.
| Brand | BBB Industries |
|---|---|
| Part Number | 311-0114 |
| Position | Reman Rack and Pinion |
| Bushings Included | Yes |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (In) | 1.938 |
| Input Shaft Length (mm) | 49.213 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 1 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M16x1.50 |
| Rack Length (In) | 51.25 |
| Rack Length (mm) | 1301.75 |
| Return Port Thread Size | M17x1.50 |
| Turns Lock To Lock | 2.875 |
This part fits 5 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2003 | Toyota | Solara | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2002 | Toyota | Solara | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2001 | Toyota | Solara | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2000 | Toyota | Solara | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 1999 | Toyota | Solara | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
