BBB Industries 313-0198 Rack and Pinion Assembly
Reman Rack and Pinion for Kia Power Steering
BBB Industries 313-0198 is a remanufactured hydraulic rack and pinion assembly for select Kia models with power steering. It is built for direct replacement service on 2001 Kia Sephia, 2001 Kia Spectra, and 2002-2004 Kia Spectra applications.
Key Features
- Remanufactured hydraulic rack and pinion assembly
- Inner tie rods included
- Bushings included
- Rack length: 44.875 in. (1139.825 mm)
- Input shaft diameter: 0.75 in. (19.05 mm)
- Input shaft length: 1.125 in. (28.575 mm)
- Pressure and return ports: M16x1.50
- Turns lock to lock: 3.125
- Distance between mounting holes: 3.31 in. (84.074 mm)
Product Details
BBB Industries Reman Rack and Pinion line focuses on remanufactured steering gear assemblies built to replace worn hydraulic units with the correct mounting, port, and shaft dimensions. Part number 313-0198 is configured for Kia Sephia and Kia Spectra power steering applications, with inner tie rods and bushings included for a more complete steering gear replacement. This part cross-references Monroe Shocks & Struts (e.g., 19321174) for the same application.
Use 313-0198 when the original rack shows internal wear, fluid leakage, excessive steering play, or uneven steering response. The hydraulic design and M16x1.50 pressure and return ports support direct replacement on the listed Kia vehicles, including 2002-2004 Kia Spectra and 2001 Kia Sephia / Kia Spectra power steering setups.
Common Issues This Part May Resolve
- Steering fluid leaks from the rack and pinion assembly
- Excessive steering wheel play or looseness
- Hard or inconsistent steering effort
- Internal rack wear causing poor steering response
- Noise or binding from a worn hydraulic steering gear
Installation Notes and Tips
Verify power steering configuration, mounting-hole spacing, input shaft dimensions, and port thread size before installation. After replacement, inspect the hydraulic system for contamination, flush the fluid if needed, and perform a professional wheel alignment. Confirm fitment by model year and build date, including 2001 Kia Sephia from 11/22/00 and 2001 Kia Spectra from 05/22/2001.
Quality Assurance
BBB Industries remanufactures steering components to restore serviceable performance in OE-style replacement applications. Part number 313-0198 is remanufactured and built for the specified Kia fitments listed above.
| Brand | BBB Industries |
|---|---|
| Part Number | 313-0198 |
| Position | Reman Rack and Pinion |
| Bushings Included | Yes |
| Distance Between Mounting Holes (In) | 3.31 |
| Distance Between Mounting Holes (mm) | 84.074 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.75 |
| Input Shaft Diameter (mm) | 19.05 |
| Input Shaft Length (In) | 1.125 |
| Input Shaft Length (mm) | 28.575 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M16x1.50 |
| Rack Length (In) | 44.875 |
| Rack Length (mm) | 1139.825 |
| Return Port Thread Size | M16x1.50 |
| Turns Lock To Lock | 3.125 |
This part fits 5 vehicles. Search below:
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2004 | Kia | Spectra | 1.8L | L4 | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2003 | Kia | Spectra | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion | ||
| 2002 | Kia | Spectra | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion | ||
| 2001 | Kia | Sephia | N/A | Power Steering; From 11/22/00; Reman Rack and Pinion | ||
| 2001 | Kia | Spectra | N/A | Power Steering; From 05/22/2001; Reman Rack and Pinion |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
