BBB Industries 313-0210 Rack and Pinion Assembly
Reman Rack and Pinion for Hyundai Tiburon
BBB Industries 313-0210 is a remanufactured hydraulic rack and pinion assembly for select 2003-2008 Hyundai Tiburon models equipped with power steering. It is built for direct steering-system replacement where precise rack travel, correct port sizing, and OE-style mounting dimensions matter.
The BBB Industries Reman Rack and Pinion line focuses on remanufactured steering components for repair applications that require factory-style fit and hydraulic operation. Part number 313-0210 follows that approach with application-specific dimensions and included inner tie rods.
- Remanufactured hydraulic rack and pinion assembly
- Fits 2003-2008 Hyundai Tiburon with power steering
- Inner tie rods included; outer tie rods not included
- Rack length: 48.438 in. (1230.313 mm)
- Turns lock to lock: 2.563
- Input shaft diameter: 0.625 in. (15.875 mm)
- Pressure port thread size: M14x1.50
- Return port thread size: M16x1.50
- Two mounting holes with 4.69 in. (119.126 mm) spacing
This rack and pinion assembly is used to restore steering response in a Hyundai Tiburon when the original unit has worn internal seals, excessive play, fluid leakage, or inconsistent steering effort. Part number 313-0210 also cross-references 19321184 for the same application.
Fitment Details
Fits 2003-2008 Hyundai Tiburon, N/A, with power steering.
Installation Notes
Verify hydraulic line thread sizes, mounting-hole spacing, and input shaft dimensions before installation. Transfer or replace related steering components as needed during service, and perform a full alignment after the rack and pinion assembly is installed. Confirm the vehicle is equipped with power steering before ordering.
Quality Assurance
BBB Industries supplies remanufactured steering components built around application-specific specifications for hydraulic rack replacement. Part number 313-0210 is remanufactured to match the listed fitment and dimensional requirements for the Hyundai Tiburon platform.
| Brand | BBB Industries |
|---|---|
| Part Number | 313-0210 |
| Position | Reman Rack and Pinion |
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 4.69 |
| Distance Between Mounting Holes (mm) | 119.126 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.625 |
| Input Shaft Diameter (mm) | 15.875 |
| Input Shaft Length (In) | 1 |
| Input Shaft Length (mm) | 25.4 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M14x1.50 |
| Rack Length (In) | 48.438 |
| Rack Length (mm) | 1230.313 |
| Return Port Thread Size | M16x1.50 |
| Turns Lock To Lock | 2.563 |
This part fits 6 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2008 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2007 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2006 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2005 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2004 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2003 | Hyundai | Tiburon | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
