BBB Industries 313-0233 Rack and Pinion Assembly
Reman Rack and Pinion for Sorento
BBB Industries 313-0233 is a remanufactured hydraulic rack and pinion assembly for the 2007-2009 Kia Sorento with power steering. It is built for direct replacement service and includes inner tie rods, with a 47-inch rack length and M16x1.50 pressure and return port threads.
The BBB Industries Reman Rack and Pinion line focuses on remanufactured steering gear assemblies for OE-style replacement needs. Part number 313-0233 follows that approach with application-specific dimensions and hydraulic port sizing for the Kia Sorento platform.
- Fits 2007-2009 Kia Sorento, N/A
- Hydraulic rack and pinion assembly for power steering systems
- Remanufactured unit for steering gear replacement
- Inner tie rods included; outer tie rods not included
- 47-inch rack length with 3.625 turns lock to lock
- Pressure and return ports threaded M16x1.50
- Two mounting holes with 6.63-inch mounting-hole spacing
- Input shaft diameter: 0.812 in. / 20.625 mm
This part cross-references OE numbers 57710-3E200 and 19321202 for the same application.
Common Replacement Uses
- Steering play or looseness in the rack assembly
- Hydraulic steering fluid leakage at the rack
- Binding, rough steering, or inconsistent steering effort
- Excessive free play from worn internal rack components
- Replacement after failure of the original power steering rack
Installation Notes
Verify hydraulic port thread size, mounting-hole spacing, input shaft dimensions, and rack length before installation. This 313-0233 assembly is for Kia Sorento models equipped with power steering and should be matched to the vehicle’s steering configuration before service. Outer tie rods are not included, so reuse or replacement should be confirmed separately during repair planning.
Quality Assurance
BBB Industries remanufactured steering components are built for replacement service in OE-style applications. Part number 313-0233 is remanufactured and specified for the 2007-2009 Kia Sorento power steering application.
| Brand | BBB Industries |
|---|---|
| Part Number | 313-0233 |
| Position | Reman Rack and Pinion |
| Bushings Included | No |
| Distance Between Mounting Holes (In) | 6.63 |
| Distance Between Mounting Holes (mm) | 168.402 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.812 |
| Input Shaft Diameter (mm) | 20.625 |
| Input Shaft Length (In) | 1.375 |
| Input Shaft Length (mm) | 34.925 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M16x1.50 |
| Rack Length (In) | 47 |
| Rack Length (mm) | 1193.8 |
| Return Port Thread Size | M16x1.50 |
| Turns Lock To Lock | 3.625 |
This part fits 3 vehicles. Search below:
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2009 | Kia | Sorento | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2008 | Kia | Sorento | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
| 2007 | Kia | Sorento | N/A | Compatible with vehicles equipped with power steering.; Reman Rack and Pinion |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
