BBB Industries 313-0358 Rack and Pinion Assembly

Hydraulic Rack and Pinion for Genesis Coupe

BBB Industries Reman Rack and Pinion 313-0358 is a remanufactured hydraulic rack and pinion assembly for select Hyundai Genesis Coupe applications. It is built for vehicles equipped with power steering and includes inner tie rods for a direct steering system replacement.

Key Features

• Remanufactured hydraulic rack and pinion assembly
• Includes inner tie rods
• Pressure port thread size: 16mm x 1.5
• Return port thread size: 16mm x 1.5
• Rack length: 42.875 in. (1089.025 mm)
• Turns lock to lock: 2.688
• Input shaft diameter: 0.688 in. (17.463 mm)
• Input shaft length: 1.5 in. (38.1 mm)
• Distance between mounting holes: 3.563 in. (90.488 mm)

Product Details

BBB Industries 313-0358 is part of the Reman Rack and Pinion line, a remanufactured steering component range focused on restoring OE-style fit and function for hydraulic steering systems. This rack and pinion assembly is specified for 2010-2016 Hyundai Genesis Coupe models equipped with power steering, and it cross-references 57700-2M001 and 57700-2M201 for the same application. The Hyundai Genesis Coupe uses a hydraulic steering setup in these applications, so matching the port thread size, input shaft dimensions, and mounting-hole spacing is important when replacing the steering gear.

What It Helps Address

• Excessive steering play or looseness
• Fluid leakage from the steering gear assembly
• Binding, rough steering, or inconsistent steering effort
• Internal wear in the rack and pinion mechanism
• Restoring steering response on a Hyundai Genesis Coupe with hydraulic power steering

Installation Notes and Tips

Verify the vehicle is a 2010-2016 Hyundai Genesis Coupe with power steering before ordering. Confirm the hydraulic port thread size, input shaft dimensions, rack length, and mounting-hole spacing against the original unit to ensure proper alignment and connection. Outer tie rods are not included, and bushings are not included. Professional installation and a complete steering inspection are recommended after replacement.

Quality Assurance

BBB Industries remanufactures steering components to meet application-specific requirements for fit and function. This 313-0358 rack and pinion is a remanufactured part built for direct replacement use in the listed Hyundai Genesis Coupe applications.
