BBB Industries N103-0233 Rack and Pinion Assembly
| Brand | BBB Industries N103-0233 |
|---|---|
| Bushings Included | No |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.745 |
| Input Shaft Diameter (mm) | 18.918 |
| Input Shaft Length (In) | 1.438 |
| Input Shaft Length (mm) | 36.513 |
| New or Remanufactured | New |
| Number of Mounting Holes | 1 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | 18mmX1.5 |
| Rack Length (In) | 50.313 |
| Rack Length (mm) | 1277.938 |
| Return Port Thread Size | 16mmX1.5 |
| Turns Lock To Lock | 3 |
| Product line | New Rack and Pinion |
| Fits | Pontiac · 3 vehicles |
New rack and pinion. Hydraulic design with inner tie rods included.
One mounting hole for straightforward installation.
3 turns lock to lock for responsive steering control.
Cross-references 19320529 for the same application. See all 1.
BBB Industries New Rack and Pinion for Pontiac GTO
Restore precise steering response with this BBB Industries New Rack and Pinion assembly, part number N103-0233. It is a new hydraulic rack and pinion built for 2004-2006 Pontiac GTO applications equipped with power steering, with inner tie rods included for a more complete steering service.
Key Features
- Brand: BBB Industries New Rack and Pinion
- Part number: N103-0233
- Fits 2004-2006 Pontiac GTO, power steering applications
- Hydraulic rack and pinion assembly
- Inner tie rods included
- New, not remanufactured
- Pressure port thread size: 18mm x 1.5
- Return port thread size: 16mm x 1.5
- Turns lock to lock: 3
- Rack length: 50.313 in. (1277.938 mm)
Product Details
The BBB Industries New Rack and Pinion line focuses on replacement steering gear assemblies for vehicles that need accurate hydraulic steering performance. This N103-0233 unit is built for the Pontiac GTO platform and matches the listed input shaft dimensions, mounting layout, and port thread sizes for direct application matching. If you are searching for a Pontiac GTO rack and pinion assembly, a hydraulic steering gear replacement, or BBB Industries N103-0233 for 2004-2006 Pontiac GTO power steering, this part is built around those specifications.
This part cross-references Monroe Shocks & Struts (e.g., 19320529) for the same application.
Common Steering Issues Addressed
- Excessive steering play or delayed steering response
- Fluid leakage from a worn hydraulic rack assembly
- Uneven steering feel caused by internal rack wear
- Noisy or inconsistent steering operation
- Need for a direct replacement during steering system repair
Installation Notes and Tips
Verify hydraulic port thread sizes, input shaft dimensions, and mounting configuration before installation. This rack and pinion is listed for vehicles equipped with power steering and uses one mounting hole. Inspect related steering components, fluid condition, and alignment settings during replacement. Professional installation and a post-installation wheel alignment are recommended after steering gear service.
Quality Assurance
BBB Industries supplies new steering components built to match the listed application details for the 2004-2006 Pontiac GTO. Part number N103-0233 is specified as a new hydraulic rack and pinion assembly with inner tie rods included and no outer tie rods or bushings included.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2006 | Pontiac | GTO | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
| 2005 | Pontiac | GTO | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
| 2004 | Pontiac | GTO | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
| No rows match your filter. | ||||
