BBB Industries N305-0180 Rack and Pinion Assembly
| Brand | BBB Industries N305-0180 |
|---|---|
| Bushings Included | Yes |
| Distance Between Mounting Holes (In) | 19.13 |
| Distance Between Mounting Holes (mm) | 485.902 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.694 |
| Input Shaft Diameter (mm) | 17.628 |
| Input Shaft Length (In) | 2.75 |
| Input Shaft Length (mm) | 69.85 |
| New or Remanufactured | New |
| Number of Mounting Holes | 4 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M16x1.50 |
| Rack Length (In) | 49.938 |
| Rack Length (mm) | 1268.413 |
| Return Port Thread Size | M16x1.50 |
| Turns Lock To Lock | 2.938 |
| Product line | New Rack and Pinion |
| Fits | Honda · 5 vehicles |
New rack and pinion. Hydraulic assembly with bushings and inner tie rods included.
OE direct replacement. Built as a complete steering gear assembly for straightforward service.
Precision steering response. 2.938 turns lock to lock for responsive control.
Cross-references 53601-SWA-A03 and 19320632 for the same application. See all 2.
BBB Industries N305-0180 Rack and Pinion for Honda CR-V
BBB Industries N305-0180 is a new hydraulic rack and pinion assembly for select 2007-2011 Honda CR-V applications. It is built for Japan-built CR-V models with power steering and includes inner tie rods and bushings for a complete steering gear replacement.
Key Features
- New rack and pinion assembly from BBB Industries New Rack and Pinion
- Fits 2007-2011 Honda CR-V, power steering, Japan built
- Hydraulic steering gear with 2.938 turns lock to lock
- Inner tie rods included; outer tie rods not included
- Bushings included for mounting support
- Pressure and return ports use M16 x 1.50 thread size
- Rack length: 49.938 in. / 1268.413 mm
- Distance between mounting holes: 19.13 in. / 485.902 mm
- Input shaft diameter: 0.694 in. / 17.628 mm
- Input shaft length: 2.75 in. / 69.85 mm
Detailed Description
BBB Industries N305-0180 is a hydraulic rack and pinion assembly engineered for direct replacement in 2007-2011 Honda CR-V models with power steering and Japan-built configuration. The BBB Industries New Rack and Pinion line focuses on replacement steering components built to match the original application layout, and this unit includes inner tie rods and bushings to support a cleaner steering gear service. This part cross-references Honda 53601-SWA-A03 and Cardone 19320632 for the same application.
Common Problems This Part Can Address
- Excessive steering play or loose steering feel
- Fluid leakage from the hydraulic steering gear
- Uneven steering response during turns
- Worn internal rack components affecting road feel
- Noise or binding from a failing rack and pinion assembly
Installation Notes and Tips
Verify the vehicle is a 2007-2011 Honda CR-V with power steering and Japan-built configuration before installation. Confirm pressure and return line thread sizes, mounting hole spacing, and input shaft dimensions against the original unit. Because outer tie rods are not included, reuse or replace them separately as needed during the steering repair.
Quality Assurance
BBB Industries supplies this new rack and pinion assembly as a direct-fit steering replacement for the listed Honda CR-V applications. Confirm all OE-style dimensions and port specifications before installation to ensure proper steering system alignment and hydraulic connection.
| Year | Make | Model | Notes |
|---|---|---|---|
| 2011 | Honda | CR-V | Power Steering; Japan Built; New Rack and Pinion |
| 2010 | Honda | CR-V | Power Steering; Japan Built; New Rack and Pinion |
| 2009 | Honda | CR-V | Power Steering; Japan Built; New Rack and Pinion |
| 2008 | Honda | CR-V | Power Steering; Japan Built; New Rack and Pinion |
| 2007 | Honda | CR-V | Power Steering; Japan Built; New Rack and Pinion |
