BBB Industries N313-0298 Rack and Pinion Assembly
| Brand | BBB Industries N313-0298 |
|---|---|
| Bushings Included | Yes |
| Distance Between Mounting Holes (In) | 3.81 |
| Distance Between Mounting Holes (mm) | 96.774 |
| Hydraulic or Electric | Hydraulic |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.625 |
| Input Shaft Diameter (mm) | 15.875 |
| Input Shaft Length (In) | 1.5 |
| Input Shaft Length (mm) | 38.1 |
| New or Remanufactured | New |
| Number of Mounting Holes | 2 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | M14X1.50 |
| Rack Length (In) | 43.75 |
| Rack Length (mm) | 1111.25 |
| Return Port Thread Size | M16X1.50 |
| Turns Lock To Lock | 3.25 |
| Product line | New Rack and Pinion |
| Fits | Hyundai · 3 vehicles |
New assembly. Fresh rack and pinion unit for a clean replacement.
Hydraulic design. Delivers responsive steering feel with fluid-assisted operation.
Inner tie rods included. Saves time by supplying key steering components together.
Cross-references 57700-2B000 and 19321241 for the same application. See all 2.
BBB Industries N313-0298 Rack and Pinion
BBB Industries N313-0298 is a new hydraulic rack and pinion assembly for steering service on select Hyundai applications. It is built for 2007-2009 Hyundai Santa Fe models equipped with power steering, with fitment confirmed for the Santa Fe across those model years.
Key Features
- New rack and pinion assembly from BBB Industries New Rack and Pinion
- Hydraulic steering design
- Inner tie rods included
- Bushings included
- 2 mounting holes with 3.81 in. (96.774 mm) mounting-hole spacing
- Input shaft diameter: 0.625 in. (15.875 mm)
- Input shaft length: 1.5 in. (38.1 mm)
- Rack length: 43.75 in. (1111.25 mm)
- Pressure port thread size: M14x1.50
- Return port thread size: M16x1.50
- 3.25 turns lock to lock
Product Details
The BBB Industries New Rack and Pinion line focuses on replacement steering gear assemblies built for direct service applications. This N313-0298 rack and pinion assembly is a hydraulic unit with inner tie rods included and bushings included, making it a complete steering gear replacement for the specified Hyundai Santa Fe fitment. If you are searching for a Hyundai Santa Fe rack and pinion, Hyundai Santa Fe steering gear, or N313-0298 replacement rack assembly, this part matches the listed application and key dimensional specs.
This part cross-references Hyundai 57700-2B000 and Cardone 19321241 for the same application.
Common Repair Uses
- Steering play or looseness in the Hyundai Santa Fe
- Fluid leakage from the hydraulic rack and pinion assembly
- Rough or inconsistent steering response
- Excessive steering effort during turns
- Wear in the steering gear requiring replacement
Installation Notes
Fits 2007-2009 Hyundai Santa Fe, power steering. Verify port thread sizes, input shaft dimensions, mounting-hole spacing, and steering linkage condition before installation. Because this is a hydraulic rack and pinion assembly, the system should be inspected for fluid condition, leaks, and contamination during service. Confirm alignment after installation and follow the vehicle service procedure for bleeding the power steering system.
Quality Assurance
BBB Industries supplies this new rack and pinion assembly as a replacement steering component for the listed Hyundai Santa Fe applications. The N313-0298 part number is provided for accurate identification when ordering or cross-referencing the correct steering gear assembly.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2009 | Hyundai | Santa Fe | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
| 2008 | Hyundai | Santa Fe | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
| 2007 | Hyundai | Santa Fe | N/A | Compatible with vehicles equipped with power steering.; New Rack and Pinion |
