BBB Industries N502-0123 Steering Gear

New Steering Gear for Ram Trucks

BBB Industries N502-0123 is a new electric steering gear built for select Dodge Ram heavy-duty applications. It is specified with a 1.25 in. output shaft diameter, 0.72 in. input shaft diameter, 26 input shaft splines, 32 output shaft splines, and 4.25 turns lock to lock.

The BBB Industries New Steering Gear line focuses on replacement steering components built to match the original application requirements for steering feel, port sizing, and mounting layout. This N502-0123 unit includes an installation kit and is configured for electric steering systems.

Key Features

• Brand: BBB Industries
• Brand line: New Steering Gear
• Part number: N502-0123
• New steering gear for electric steering systems
• 1.25 in. output shaft diameter
• 0.72 in. input shaft diameter
• 26-spline input shaft and 32-spline output shaft
• M18x1.50 pressure port thread size and inlet size
• M16x1.50 outlet port thread size and return port thread size
• 3 mounting holes
• 4.25 turns lock to lock
• Installation kit included

Detailed Description

BBB Industries N502-0123 is a new steering gear for Dodge Ram 2500 and Dodge Ram 3500 trucks equipped with power steering. It is listed for 1997-2002 Dodge Ram 2500, 1997-2002 Dodge Ram 3500, 2000 Dodge Ram 2500 Standard Cab, 2000 Dodge Ram 3500 Standard Cab, and 2001-2002 Dodge Ram 3500 Standard Cab with Production Code Z3B. The part number N502-0123 also cross-references 19321326 and 52113500AB for the same application.

Use this steering gear when replacing a worn or leaking unit on a Dodge Ram 2500 or Dodge Ram 3500 with the specified power steering configuration. The port thread sizes, spline counts, and mounting pattern are provided to support direct replacement selection for the correct truck application.

What It Helps Fix

• Excessive steering play or loose steering response
• Fluid leakage from the steering gear housing or ports
• Hard steering effort caused by internal wear
• Steering gear noise related to worn internal components
• Incorrect steering feel after replacing a failed gear

Installation Notes

Verify the vehicle’s steering system type, cab configuration, and production code before ordering. Confirm the input and output shaft spline counts, port thread sizes, and mounting hole layout against the original steering gear. Bleed the power steering system after installation and inspect for leaks, proper centering, and full steering travel.

Quality Assurance

BBB Industries supplies replacement steering components through its New Steering Gear product line for service applications that require a new unit rather than a remanufactured part. This part is built to the listed specifications for the correct Dodge Ram 2500 and Dodge Ram 3500 fitments.
