Bosal 096-1650 Catalytic Converter - Rear

Overview of the Bosal BRExhaust Catalytic Converter

The Bosal BRExhaust Federal Direct-Fit Premium Load OBDII Catalytic Converter (Part Number 096-1650) is designed specifically for Toyota Prius models. This direct-fit catalytic converter meets federal and EPA compliance standards, ensuring proper emissions control and reliable performance.

• Direct-fit design for Toyota Prius
• Federal and EPA compliant catalytic converter
• Stainless steel construction for durability
• Ceramic substrate for efficient emissions reduction
• Includes mounting hardware, gasket, and clamp
• Single inlet and outlet with bolt-on and clamp-on attachments
• Oxygen sensor port located post-converter
• Overall length: 15.875 inches; body length: 9.125 inches
• Body dimensions: 4 inches height and width, round spun body shape

BRExhaust Federal Direct-Fit Premium Load OBDII Product Line

The BRExhaust Federal Direct-Fit Premium Load OBDII Catalytic Converter line by Bosal focuses on providing direct-fit solutions that comply with federal emissions regulations. This product line is engineered to meet OBDII requirements, ensuring compatibility with onboard diagnostics systems. The premium load substrate enhances catalytic efficiency, making it suitable for vehicles like the Toyota Prius that require precise emissions control.

Product Details and Specifications

This catalytic converter features a stainless steel body with a spun round shape measuring 4 inches in height and width, and 9.125 inches in body length. The overall length of the unit is 15.875 inches. It has a single inlet and outlet, with a 2.5-inch inlet diameter and a 1.875-inch outlet diameter. The inlet attachment is bolt-on, while the outlet uses a clamp-on connection. The ceramic substrate inside is designed for premium load capacity, optimizing emissions reduction. Additionally, the converter includes one oxygen sensor port located post-converter to maintain accurate emissions monitoring.

Common Applications and Problem Solving

• Replacement for faulty or clogged catalytic converters on Toyota Prius models
• Restores proper emissions control to pass federal and EPA inspections
• Resolves check engine light issues related to catalytic converter performance
• Improves exhaust flow and reduces harmful emissions
• Maintains OBDII system functionality with correct sensor placement

Installation Notes and Tips

This catalytic converter is designed for direct-fit installation on compatible Toyota Prius vehicles. The bolt-on inlet and clamp-on outlet attachments simplify the replacement process. Ensure the oxygen sensor is properly installed in the post-converter sensor port to maintain accurate emissions readings. While mounting hardware, gasket, and clamp are included, verify all connections are secure and free of leaks during installation.

Quality Assurance and Warranty

Constructed from durable stainless steel with a ceramic substrate, this Bosal catalytic converter is built to meet federal emissions standards. The BRExhaust Federal Direct-Fit Premium Load OBDII Catalytic Converter undergoes quality checks to ensure compliance and performance. Please refer to Bosal's warranty policy for specific coverage details related to this part number 096-1650.
