Cardone 18-B4693 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper w/Bracket 18-B4693

The Cardone Unloaded Caliper w/Bracket 18-B4693 is a remanufactured disc brake caliper designed specifically for Chevrolet Camaro and Pontiac Firebird models. Engineered with a durable oil emulsion finish and gray color, this caliper ensures reliable braking performance and corrosion resistance.

• Remanufactured disc brake caliper with bracket
• Compatible with Chevrolet Camaro and Pontiac Firebird
• Steel piston material with two pistons (44.958 mm diameter)
• Includes installation hardware kit (mounting bolts not included)
• Bleeder and inlet port size: M10x1.0
• Oil emulsion brake caliper finish for corrosion protection

About the Cardone Unloaded Caliper w/Bracket Product Line

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured brake calipers that come complete with the necessary bracket and hardware kit for installation. This line is designed to provide a cost-effective replacement option while maintaining OEM specifications. The unloaded design means the caliper does not include brake pads, allowing for flexibility in pad selection based on vehicle requirements.

Detailed Product Description

This Cardone disc brake caliper (part number 18-B4693) features two steel pistons measuring approximately 1.77 inches (44.958 mm) in diameter, providing consistent and even clamping force on the brake rotor. The caliper’s gray oil emulsion finish helps resist rust and wear over time. It includes a bleeder port and inlet port both sized M10x1.0, compatible with standard brake lines for Chevrolet Camaro and Pontiac Firebird models. The package contains the caliper, bracket, and a hardware kit to facilitate installation, though mounting bolts are not included. The caliper uses silicone grease on floating caliper mounting pins to ensure smooth operation and reduce noise.

Common Applications and Issues Addressed

• Replacement for worn or leaking disc brake calipers on Chevrolet Camaro and Pontiac Firebird
• Resolves brake pedal issues caused by air in the hydraulic system
• Addresses uneven braking or vehicle pulling to one side during braking
• Eliminates brake squeal related to caliper hardware or mounting pin lubrication
• Restores proper brake function when calipers are suspected to cause low brake pedal feel

Installation Notes and Tips

• Use brake fluid recommended by the original equipment manufacturer (OEM) to maintain system integrity
• Apply silicone grease on floating caliper mounting pins to prevent squeal and ensure smooth caliper movement
• Verify bleeder and inlet port sizes (M10x1.0) match vehicle brake lines before installation
• New hardware is included with the caliper, but mounting bolts must be sourced separately if needed
• Always bleed the brake system thoroughly after installation to remove air and restore proper pedal feel

Quality Assurance and Warranty

This Cardone remanufactured brake caliper undergoes rigorous testing to meet OEM standards for fit, form, and function. The product is backed by Cardone’s quality assurance processes to ensure reliable braking performance. Installation hardware is included to support proper mounting, and the caliper finish provides corrosion resistance for extended service life.
