Cardone 18-B4713 Disc Brake Caliper - Rear Left or Rear Right

Overview of Cardone Unloaded Caliper w/Bracket 18-B4713

The Cardone Unloaded Caliper w/Bracket 18-B4713 is a remanufactured disc brake caliper designed for reliable braking performance. This caliper is compatible with select Chevrolet, GMC, Isuzu, and Oldsmobile models including the Blazer, Bravada, Hombre, Jimmy, S10, and Sonoma.

• Remanufactured disc brake caliper with phenolic piston
• Includes caliper, bracket, and hardware kit for installation
• Brake caliper finished with oil emulsion in gray color
• Bleeder and inlet port size: M10x1.0
• Installation hardware included; mounting bolts not included
• Compatible with DOT 3 and DOT 4 brake fluids as recommended by OEM

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the mounting bracket and necessary hardware kit. This setup simplifies installation by providing all essential components except mounting bolts, ensuring a direct replacement for the original equipment on compatible vehicles. The unloaded design means brake pads are not included, allowing for flexibility in pad selection.

Technical Description and Features

This Cardone 18-B4713 caliper features a single phenolic piston measuring approximately 1.892 inches (48.06 mm) in diameter, which helps reduce heat transfer to the brake fluid. The caliper is finished with an oil emulsion coating in gray to resist corrosion. Both the bleeder and inlet ports use an M10x1.0 thread size, matching OEM specifications for proper brake line and bleeder screw fitment. The caliper uses silicone grease on floating caliper mounting pins to ensure smooth operation and prevent seizing.

Compatible Vehicles and Applications

• Chevrolet Blazer
• GMC Jimmy
• Isuzu Hombre
• Oldsmobile Bravada
• Chevrolet S10 and GMC Sonoma

This caliper is designed specifically for these models, providing a direct replacement for worn or damaged front disc brake calipers.

Common Brake Issues Addressed

• Low brake pedal caused by air in the brake system
• Brake squeal due to caliper or hardware issues
• Vehicle pulling to one side during braking
• Caliper piston sticking or seizing
• Corrosion or damage to original caliper housing

Installation Notes and Tips

When installing the Cardone 18-B4713 caliper, always use the included hardware kit for proper mounting. Note that mounting bolts are not included and should be reused if in good condition or replaced separately. Use the brake fluid type recommended by the vehicle manufacturer, typically DOT 3 or DOT 4. Apply silicone grease to the floating caliper mounting pins to ensure smooth caliper movement. Bleed the brake system thoroughly to remove any air and restore firm pedal feel.

Quality Assurance and Warranty

This remanufactured caliper undergoes a comprehensive rebuilding process to meet OEM standards. Cardone provides a limited warranty covering defects in materials and workmanship. The oil emulsion finish helps protect against corrosion, extending the service life of the caliper. Using this part helps maintain safe and consistent braking performance on your Chevrolet Blazer, GMC Jimmy, Isuzu Hombre, Oldsmobile Bravada, or related models.
