Cardone 18-B4733 Disc Brake Caliper - Front Right

Overview of Cardone Unloaded Caliper w/Bracket for Ford Windstar

The Cardone 18-B4733 Unloaded Caliper w/Bracket is a remanufactured disc brake caliper designed specifically for the Ford Windstar. Engineered to meet OE specifications, this caliper ensures reliable braking performance and durability.

• Remanufactured disc brake caliper with bracket included
• Phenolic piston material with two 1.89 inch (48.006 mm) pistons
• Brake caliper finished with oil emulsion in gray color
• Includes installation hardware kit; mounting bolts not included
• Bleeder port size M10x1.0 and inlet port size M10x1.5

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the necessary bracket and hardware kit for installation. This line is designed to provide a direct replacement for worn or damaged calipers on compatible vehicles, such as the Ford Windstar, ensuring proper fit and function without the inclusion of brake pads.

Technical Description and Features

This Cardone 18-B4733 caliper features phenolic pistons, which help reduce heat transfer to the brake fluid, minimizing the risk of brake fade. The caliper is finished with an oil emulsion coating in gray, providing corrosion resistance. It includes two pistons with an outer diameter of 1.89 inches (48.006 mm) each, suitable for the braking system of the Ford Windstar. The bleeder port and inlet port sizes are M10x1.0 and M10x1.5 respectively, matching OEM specifications. The package contains the caliper, bracket, and a hardware kit for installation, though mounting bolts are not included.

Common Applications and Problem Resolution

• Replacement for worn or leaking brake calipers on Ford Windstar models
• Addresses symptoms such as low brake pedal caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side during braking
• Eliminates brake squeal related to caliper issues
• Restores proper brake fluid sealing and piston function

Installation Notes and Tips

When installing the Cardone 18-B4733 caliper on a Ford Windstar, use the included hardware kit for proper mounting. Note that mounting bolts are not included and must be sourced separately if needed. It is recommended to use the brake fluid type specified by the vehicle manufacturer. Applying silicone grease on floating caliper mounting pins can improve caliper movement and reduce noise. Always bleed the brake system thoroughly to remove air and ensure optimal pedal feel.

Quality Assurance and Warranty

This remanufactured caliper undergoes rigorous testing to meet OEM standards for fit, form, and function. Cardone provides a warranty on this part to cover defects in materials and workmanship, supporting reliable performance for your Ford Windstar brake system.
