Cardone 18-B4866 Disc Brake Caliper - Front Left

Overview of Cardone Unloaded Caliper w/Bracket 18-B4866

The Cardone Unloaded Caliper w/Bracket 18-B4866 is a remanufactured disc brake caliper designed specifically for Chevrolet Equinox and Saturn Vue models. Engineered with a phenolic piston and finished with an oil emulsion coating, this caliper ensures reliable braking performance and corrosion resistance.

• Remanufactured disc brake caliper with bracket included
• Compatible with Chevrolet Equinox and Saturn Vue
• Phenolic piston material with two pistons (41.9354 mm diameter)
• Oil emulsion brake caliper finish in gray color
• Includes installation hardware kit (mounting bolts not included)
• Bleeder port size M10x1.0 and inlet port size M10x1.5

Product Line: Cardone Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the mounting bracket and necessary hardware for installation. This line is designed to provide a cost-effective replacement option that meets original equipment specifications, making it suitable for vehicles like the Chevrolet Equinox and Saturn Vue. The unloaded design means the caliper does not include brake pads, allowing for flexibility in pad selection.

Detailed Product Description

This Cardone disc brake caliper (part number 18-B4866) features a phenolic piston construction, which helps reduce heat transfer to the brake fluid, minimizing the risk of brake fade. The caliper is finished with an oil emulsion coating in gray, providing corrosion resistance and durability. It includes two pistons with an outer diameter of approximately 1.65 inches (41.9354 mm), ensuring even pressure distribution on the brake pads. The bleeder port and inlet port sizes are M10x1.0 and M10x1.5 respectively, matching OEM specifications for proper fitment and brake fluid flow.

Common Applications and Issues Addressed

• Replacement for worn or leaking calipers on Chevrolet Equinox and Saturn Vue
• Resolves uneven brake pad wear caused by caliper malfunction
• Addresses brake pedal issues related to caliper piston or seal failure
• Eliminates brake noise caused by sticking or seized calipers
• Improves braking performance and pedal feel by restoring proper caliper function

Installation Notes and Tips

This caliper comes with a complete hardware kit for installation; however, mounting bolts are not included and must be sourced separately. It is recommended to use silicone grease on floating caliper mounting pins to ensure smooth operation. Always use the brake fluid type specified by the vehicle manufacturer, typically DOT 3 or DOT 4. Bleed the brake system thoroughly after installation to remove any air and restore proper brake pedal height.

Quality Assurance and Warranty

Cardone remanufactured calipers undergo rigorous testing to meet or exceed OEM standards. The 18-B4866 caliper is built to provide reliable braking performance and durability. While specific warranty details are not provided here, Cardone products typically include a limited warranty covering defects in materials and workmanship. Consult product documentation or Cardone directly for exact warranty terms.
