Cardone 18-B5396 Disc Brake Caliper - Rear Right

Overview of Cardone Unloaded Caliper w/Bracket 18-B5396

The Cardone Unloaded Caliper w/Bracket 18-B5396 is a remanufactured disc brake caliper designed specifically for Ford F-150 models. Engineered to meet OEM specifications, this caliper features a phenolic piston and comes with a complete hardware kit for reliable brake system performance.

• Remanufactured disc brake caliper with phenolic piston
• Includes caliper, bracket, and installation hardware kit
• Brake caliper finish: oil emulsion with gray color
• Bleeder and inlet port size: M10x1.0
• Compatible with Ford F-150 models
• Installation hardware included; mounting bolts not included

Product Line Details: Unloaded Caliper w/Bracket

The Cardone Unloaded Caliper w/Bracket product line offers remanufactured calipers that come complete with the mounting bracket and necessary hardware kit. This design simplifies installation by providing all essential components except mounting bolts, ensuring a straightforward replacement process. The unloaded caliper means brake pads are not included, allowing for flexibility in pad selection based on vehicle requirements.

Technical Description and Features

This Cardone 18-B5396 caliper is finished with an oil emulsion coating in gray, providing corrosion resistance and durability. It features a single phenolic piston measuring approximately 2.124 inches (53.95 mm) in diameter, which helps reduce heat transfer to the brake fluid. The bleeder and inlet ports are sized M10x1.0, compatible with standard brake lines for the Ford F-150. A silicone grease is recommended for the floating caliper mounting pins to ensure smooth operation and prevent squealing noises.

Common Applications and Problem Solving

• Replaces worn or leaking disc brake calipers on Ford F-150 trucks
• Addresses symptoms of low brake pedal often caused by air in the brake system
• Helps resolve uneven braking or vehicle pulling to one side during stops
• Eliminates brake squeal related to caliper mounting pin issues
• Restores proper brake function when calipers are suspected to cause pedal softness

Installation Notes and Tips

Installation of the Cardone 18-B5396 caliper should follow OEM brake fluid recommendations, typically DOT 3 or DOT 4. The product includes a hardware kit but does not include mounting bolts, so verify bolt condition before installation. Use silicone grease on floating caliper mounting pins to reduce noise and ensure smooth caliper movement. Bleed the brake system thoroughly after installation to remove any air and restore proper pedal feel.

Quality Assurance and Warranty

This remanufactured Cardone caliper undergoes rigorous testing to meet OEM standards for fit, form, and function. While specific warranty details are not provided here, Cardone products typically come with a limited warranty covering defects in materials and workmanship. Refer to Cardone’s official warranty policy for complete terms.
